NOTES;
1. Dimensions in ( ) are in millimeters.
2. Refer to Fig. 4 and 5 for unit operating weights.
3. Remove boards at ends of unit and runners prior to rigging.
4. Rig by inserting hooks into unit base rails as shown. Use corner post from packaging to protect coil from
damage. Use bumper boards for spreader bars on all units.
5. Weights do not include optional economizer. Add 90 lb (41 kg) for economizer weight.
6. Weights given are for aluminum evaporator and condenser coil plate fins.
A CAUTION
All panels must be in place when rigging.
UNIT
48TJ
MAXIMUM
SHIPPING WEIGHT
DIMENSIONS
A
B
lb
kg
Ft-in.
mm
Ft-in.
mm
016
1775
805
6-11V
2
2121
3-5
1041
020
1875
850
6-11 Vg
2121
3-3
991
024
1985
900
6-11 Vg
2121
3-2
965
028
2135
968
6-11 Vg
2121
3-2
965
Fig. 3 — Rigging Detaiis
