PKG. NO. REF.
CURB
HEIGHT
DESCRIPTION
CRRFCURB010A00
2" (305)
Standard Curb 14" High
CRRFCURB011A00
2'- 0"(610)
Standard Curb for Units Requiring High Installation
CRRFCURB012A00
2'- 0"(610)
Side Supply and Return Curb for High Installation
NOTES:
K ROOF CURB ACCESSORY 15 SHIPPED D15AS5EHBLED.
2. INSULATED PANELS: 1* THICK NEOPRENE COATED 1-1/2 LB DENSITY
3. DIMENSIONS IN C ) ARE IN MILLIMETERS.
4. c=i>
direction
of
AIR FLOW
5. ROOFCURB: 16 GA. CVA03-56) STL.
S. A 30 DEGREE ELBOW MUST BE INSTALLED ON THE SUPPLY DUCT
WORK BELOW THE UNIT DISCHARGE FOR UNITS EQUIPPED WITH
ELECTRIC HEATERS.
NOTE;
TO PREVENT THE HAZARD OF STAGNANT WATER
BUllD-UP IN THE DRAIN PAN OF THE INDOOP
SECTION, UNIT CAN ONLY BE PITCHED AS SHOWN.
.... .
CONDENSER
AND
COMPRESSOR
END
A-
DIMENSIONS (degrees ond inches)
UNIT
A
B
DEG.
IN.
DEG.
IN.
ALL
.26
.45
.28
.43
NOM. 5/4 K
A
(323 X (1023
TYP. 4 PLC5
UNIT LEVELING TOLERANCES
- n o m e d g e o F u n i t t o h o r i z c n t o L .
COUNTER FLASHING;
(FIELD SUPPLIED)
•ROOFING FELT
(FIELD SUPPLIED)
■CANT STRIP
(FIELD SUPPLIED)
ROOFING MATERIAL
(FIELD SUPPLIED)
CRRFCURB012A00'0NLY) 0
Fig. 2 — Roof Curb Details
