Carrier 48TJ016-028 - Manual

48TJ016-028
Single-Package Rooftop Units
Electric Cooling/Gas Heating
Installation, Start-Up and
Service Instructions
CONTENTS
Page
SAFETY CONSIDERATIONS............................................I
INSTALLATION.............................................................2-31
Step 1 — Provide Unit Support............................................2
• ROOF CURB
• ALTERNATE UNIT SUPPORT
Step 2 —- Rig and Place Unit............................................... 2
• POSITIONING
• ROOF MOUNT
Step 3 — Field Fabricate Ductwork.....................................9
Step 4 — Make Unit Duct Connections............................... 9
Step 5 — Install Flue Hood and Wind Baffle..................... 9
Step 6 — Trap Condensate Drain........................................9
Step 7 — Orifice Change.................................................... 10
Step 8 — Install Gas Piping................................................ 11
Step 9 — Make Electrical Connections............................. 11
• FIELD POWER SUPPLY
• FIELD CONTROL WIRING
• OPTIONAL NON-FUSED DISCONNECT
• OPTIONAL CONVENIENCE OUTLET
Step 10 — Make Outdoor-Air Inlet Adjustments,. 14
Step 11 — Install Outdoor-Air Hood................................ 14
Step 12 — Install All Accessories.......................................15
MOTORMASTER® I CONTROL INSTALLATION
MOTORMASTER V CONTROL INSTALLATION
Step 13 — Adjust Factory-Installed Options....................17
PREMIERLINKTM CONTROL
ENTHALPY SWITCH/RECEIVER
OUTDOOR ENTHALPY CONTROL
DIFFERENTIAL ENTHALPY CONTROL
ENTHALPY SENSORS AND CONTROL
OPTIONAL ECONOMISERIV AND
ECONOMI$ER2
ECONOMI$ERIV STANDARD SENSORS
ECONOMI$ERIV CONTROL MODES
Step 14 — Install Humidlstat for
Optional MoistureMISer’'“ Package............................ 29
START-UP......................................................................31-38
SERVICE........................................................................ 39-47
TROUBLESHOOTING................................................ 48 52
INDEX...................................................................................53
START-UP CHECKLIST.............................................. CL 1
SAFETY CONSIDERATIONS
Installation and seiTicing of air-conditioning equipment can
be hazardous due to system pressure and electrictil compo­
nents, Only triiined and qualified service personnel should in­
stall, repair, or service air-conditioning equipment.
Untrained personnel can perform basic maintenance func­
tions of cleaning coils and filters and replacing filters. All other
operations should be performed by trained service personnel.
When working on air-conditioning equipment, observe
precautions in the literature, tags and labels attached to the unit,
and other safety precautions that may apply.
Follow all siifety codes. Wear safety glasses and work
gloves. Use quenching cloth for unbrazing operations. Have
fire extinguishers available for till brazing operations.
A WARNING
Before performing service or maintenance operations on
unit, turn off main power switch to unit. Electrical shock
could cause personal injuiy.
A WARNING
1. Improper instiillation, adjustment, alteration, service,
or maintenance can cause properfy ckimage, personal
injuiy, or loss of life. Refer to the User's Information
Manual provided with this unit for more details.
2, Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of tliis or any otlier
appliance.
What to do if you smell gas:
1. DO NOT tiy to light any appliance.
2. DO NOT touch any electrical switch, or use any
phone in your building,
3. IMMEDIATELY call your gas supplier from a neigh­
bor’s phone. Follow the gas supplier’s instmctions.
4. If you cannot reach your gas supplier, cttll the fire
deparfment.
A WARNING
Disconnect gas piping from unit when pressure testing at
pressure greater than 0.5 psig. Pressures greater than
0.5 psig will cause gas valve damage resulting in haziu'dous
condition. If gas valve is subjected to pressure greater than
0.5 psig, it must be replaced before use. When pressure
testing field-supplied gas piping at pressures of 0.5 psig or
less, a unit connected to such piping must be isolated by
closing the manual gas valve(s).
IMPORTANT: Units have high ambient operating lim­
its. If limits are exceeded, the units will automatically
lock the compressor out of operation. Manuiil reset will
be required to restiuf the compressor.
