DSE Model 71xx Series Control & Instrumentation System Mk2 Operators Manual
50 Part No. 057-113 71xx Series OPERATING MANUAL ISSUE 2 12/08/2010 ADM
OUTPUT SOURCE LIST 7110 7120
MPU CAN MPU CAN
0 Not used
1 Air Flap relay (1)
2 Arm safety on alarms
3 Audible Alarm
4 Battery over volts warning
5 Battery under volts warning
6 CAN ECU data fail X X
7 CAN ECU error X X
8 CAN ECU fail X X
9 CAN ECU power X X
10 CAN ECU stop X X
11 Charge alternator shutdown
12 Charge alternator warning
13 Close Gen output
14 Close Gen output pulse
15 Close Mains output X X
16 Close Mains output pulse X X
17 Combined mains failure X X
18 Common Alarm
19 Common Electrical Trip
20 Common Shutdown
21 Common Warning
22 Cooling down
23 Dig Input A
24 Dig Input B
25 Dig Input C
26 Dig Input D
27 Dig Input E
28 Dig Input F
29 Emergency stop
30 Energise to stop
31 Fail to come to rest
32 Fail to start
33 Fuel relay
34 Gas choke on X X
35 Gas ignition X X
36 Generator Available
37 Generator over voltage shutdown
38 RESERVED
39 RESERVED
40 Loss of magnetic pickup signal X X
41 Low fuel level
42 Low oil pressure (shutdown)
43 Mains high frequency X X
44 Mains high voltage X X
45 Mains low frequency X X
46 Mains low voltage X X
47 Open Gen Output
48 Open Gen Output pulse
49 Open Mains Output X X
50 Open Mains Output Pulse X X
51 Over Frequency shutdown
52 Over speed shutdown
53 Preheat During Preheat Timer
54 Preheat Until End of Crank
55 Preheat Until End of Safety Timer
56 Preheat Until End of Warming Timer
57 Smoke limiting
58 Start relay
59 Under frequency shutdown
60 Under speed shutdown
61 Waiting for manual restore X X
