DSE Model 71xx Series Control & Instrumentation System Mk2 Operators Manual
14 Part No. 057-113 71xx Series OPERATING MANUAL ISSUE 2 12/08/2010 ADM
4.1.4 CAN
PIN No DESCRIPTION CABLE
SIZE
NOTES
25 CAN port H
0.5mm²
AWG 20
Use only 120
Ω
CAN approved cable
26 CAN port L
0.5mm²
AWG 20
Use only 120
Ω
CAN approved cable
27 CAN port Common
0.5mm²
AWG 20
Use only 120 Ω CAN approved cable
NOTE:- Screened 120
Ω Ω Ω Ω
impedance cable specified for use with CAN must be used for the CAN link and
the Multiset comms link.
DSE stock and supply Belden cable 9841 which is a high quality 120
Ω Ω Ω Ω
impedance cable suitable for CAN
use (DSE part number 016-030)
NOTE:- Terminals 28 to 38 are not fitted to the DSE7100 series controllers.
4.1.5 GENERATOR / MAINS LOAD SWITCHING
PIN
No
DESCRIPTION CABLE
SIZE
NOTES
39 Output relay C
1.0mm
AWG 18
Normally configured to control load switching device
(Recommend 10A fuse)
40 Output relay C
1.0mm
AWG 18
Normally configured to control load switching device
41 Output relay D
1.0mm
AWG 18
Normally configured to control load switching device
(Recommend 10A fuse)
42 Output relay D
1.0mm
AWG 18
Normally configured to control load switching device
4.1.6 GENERATOR / MAINS VOLTAGE SENSING
PIN
No
DESCRIPTION CABLE
SIZE
NOTES
43
Generator L1 (U) voltage
monitoring 1.0mm²
AWG 18
Connect to generator L1 (U) output (AC)
(Recommend 2A fuse)
44
Generator L2 (V) voltage
monitoring 1.0mm²
AWG 18
Connect to generator L2 (V) output (AC)
(Recommend 2A fuse)
45
Generator L3 (W) voltage
monitoring 1.0mm²
AWG 18
Connect to generator L3 (W) output (AC)
(Recommend 2A fuse)
46 Generator Neutral (N) input
1.0mm²
AWG 18
Connect to generator Neutral terminal (AC)
47 Mains L1 (R) voltage monitoring
1.0mm²
AWG 18
Connect to Mains L1 (R) output (AC)
(Recommend 2A fuse)
48 Mains L2 (S) voltage monitoring
1.0mm²
AWG 18
Connect to Mains L2 (S) output (AC)
(Recommend 2A fuse)
49 Mains L3 (T) voltage monitoring
1.0mm²
AWG 18
Connect to Mains L3 (T) output (AC)
(Recommend 2A fuse)
50 Mains Neutral (N) input
1.0mm²
AWG 18
Connect to Mains Neutral terminal (AC)
NOTE:- Terminals 47-50 are not fitted to the DSE7110.
