DSE Model 71xx Series Control & Instrumentation System Mk2 Operators Manual
38 Part No. 057-113 71xx Series OPERATING MANUAL ISSUE 2 12/08/2010 ADM
CONFIGURATION PARAMETERS – INPUTS (Page 3) 7110 7120
MPU CAN MPU CAN
301 Low oil pressure enable On (1), Off (0)
302 Low oil pressure trip
0 PSI
0.00 bar
0 kPa
303 High engine temperature trip 00 deg C
304 Digital input A source 0 (Input source)
305 Digital input A polarity 0 (Polarity)
306 Digital input A action (if source = user config) 0 (Action)
307 Digital input A arming (if source = user config) 0 (Arming)
308 Digital input A activation delay (if source = user config) 0:00
309 Digital input B source 0 (Input source)
310 Digital input B polarity 0 (Polarity)
311 Digital input B action (if source = user config) 0 (Action)
312 Digital input B arming (if source = user config) 0 (Arming)
313 Digital input B activation delay (if source = user config) 0:00
314 Digital input C source 0 (Input source)
315 Digital input C polarity 0 (Polarity)
316 Digital input C action (if source = user config) 0 (Action)
317 Digital input C arming (if source = user config) 0 (Arming)
318 Digital input C activation delay (if source = user config) 0:00
319 Digital input D source 0 (Input source)
320 Digital input D polarity 0 (Polarity)
321 Digital input D action (if source = user config) 0 (Action)
322 Digital input D arming (if source = user config) 0 (Arming)
323 Digital input D activation delay (if source = user config) 0:00
324 Analogue input A sensor type
0 (sensor type)
325 Analogue input A sensor selection (temperature sensor list)
0 (pressure sensor)
326 Analogue input A (set as digital) source (oil pressure sender) 0 (Input source)
327 Analogue input A (set as digital) polarity 0 (Polarity)
328 Analogue input A (set as digital) action (if source = user config) 0 (Action)
329 Analogue input A (set as digital) arming (if source = user config) 0 (Arming)
330
Analogue input A (set as digital) activation delay (if source = user
config)
0:00
