Case a case b, Vt8300 series user interface guide, Test outputs – Viconics VT8300 Low Voltage User Interface Guide User Manual
Page 43
43
VT8300 Series
User Interface Guide
Viconics Technologies Inc.
|
9245 Langelier Blvd.
|
St.-Leonard
|
Quebec
|
Canada
|
H1P 3K9
|
Tel: (514) 321-5660
|
Fax: (514) 321-4150
028-0427-01
www.viconics.com
|
November 2014
©
2
01
4 V
ic
onic
s T
ec
hno
lo
gi
es
Inc
. A
ll r
ig
ht
s r
ese
rv
ed
.
UO11 Binary
UO9 Binary
Off
Off
Off
UO10 Binary
UO12 Binary
Off
2/2 Test outputs
TEST OUTPUTS
Note: screen Test outputs are LIVE. Any output gets displayed immediately for any value change according to the following:
1. If any BACnet priority array (1 - 16) includes a value, the displayed state background shows in red.
2. When toggling a value on the screen, the output directly energizes according to the selected value.
3. You can override any output if you bypass the Bacnet array (1 - 16).
4. It is not possible to modify the set Bacnet array values.
5. After any output state gets modified, all overrides get cancelled after 1 minute of button inactivity, or if you scroll from one screen to
another screen.
CASE A: screen 2/2 display is dependent on Control type configuration. If mode is set to Floating or On/Off, binary options show.
CASE B: screen 2/2 display is dependent on Control type configuration. If mode is set to Analog, analog options show.
UO11 Analog
0 Vdc
0 Vdc
UO12 Analog
2/2 Test outputs
CASE A
CASE B
