BACNET INSTANCE NUMBER
The default BACnet® instance number is generated by the model number and COM address of the controller. For example, The instance
number of a VT8300A5B00 with a COM address of 57 is generated as “83057”.
The default instance number appears first. To change the instance number, use number pad and press Accept and save.
Press Reset to automatic instance addressing to reset to automatic instance addressing.
0 8 3 0 0 5 7
2/2 BACnet instance
Instance number of controller
Baud rate
settings
Accept and save
Reset to automatic
instance addressing
