Form P-RDF, P/N 270069 R6, Page 9
CODE 45 - Motor Shaft volt ph Service
Factor
Power
Factor
EFF.
CODE 47A - Starter
Contactor w/24 volt coil
CODE 47B - Starter Overload
CODE 46 - Motor
Contactor (Option AN2)
Type hp P/N Mfr No. Frame fla Mfr No. P/N min max GE # P/N Mfr No. P/N
TEFC
7.5
158171 AO-E356 213T 19 1-3/8" 240 3 CL25A310T-1 151278 17.5 22.0 RTA1-T 151197 ============ ======
TEFC 158171 AO-E356 213T 9.5 1-3/8" 480 3 CL00A310T-1 151275 8.0 12.0 RTA1-N 151193 ============ ======
TEFC 158172 AO-E364 213T 7.6 1-3/8" 575 3 CL00A310T-1 151275 5.5 8.5 RTA1-M 151192 ============ ======
TEFC
10
105846 AO-K313 215T 39 1-3/8" 240 1 CL06A311M-1 203687 30.0 43.0 RTA2-E 151206 ============ ======
TEFC 158173 AO-E357 215T 30 1-3/8" 208 3 CL04A310M-1 151279 25.0 32.0 RTA1-V 151199 ============ ======
TEFC 158173 AO-E357 215T 26 1-3/8" 240 3 CL04A310M-1 151279 21.0 26.0 RTA1-U 151198 ============ ======
TEFC 158173 AO-E357 215T 13 1-3/8" 480 3 CL02A310T-1 151277 10.0 16.0 RTA1-P 151194 ============ ======
TEFC 158174 AO-E365 215T 9.6 1-3/8" 575 3 CL00A310T-1 151275 8.0 12.0 RTA1-N 151193 ============ ======
TEFC
15
142443 BAL-FM2333T 254T 38 1-5/8" 240 3 1.2 82 90.2% CL06A311M-1 203687 30.0 43.0 RTA2-E 151206 ============ ======
TEFC 142443 BAL-FM2333T 254T 19 1-5/8" 480 3 1.2 82 90.2% CL25A310T-1 151278 17.5 22.0 RTA1-T 151197 ============ ======
TEFC 142444 B-FM2333-5 254T 15 1-5/8" 575 3 1.2 82 90.2% CL02A310T-1 151277 10.0 16.0 RTA1-P 151194 ============ ======
TEFC
20
142301 BAL-FM2334T 256T 52 1-5/8" 240 3 1.2 81 89.5% CL07A311M-1 203793 42.0 55.0 RTA2-G 151202 ============ ======
TEFC 142301 BAL-FM2334T 256T 26 1-5/8" 480 3 1.2 81 89.5% CL04A310M-1 151279 25.0 32.0 RTA1-V 151199 ============ ======
TEFC 142302 B-FM2334T-5 256T 20.6 1-5/8" 575 3 1.2 81 89.5% CL25A310T-1 151278 17.5 22.0 RTA1-T 151197 ============ ======
EE
1
105659 AO-E103 N143T 3.1 7/8" 208 3 CL00A310T-1 151275 2.5 4.1 RTA1-K 151190 ============ ======
EE 159328 AO-E1015 143T 2.7 7/8" 240 3 CL00A310T-1 151275 2.5 4.1 RTA1-K 151190 ============ ======
EE 159328 AO-E1015 143T 1.4 7/8" 480 3 CL00A310T-1 151275 1.0 1.5 RTA1-G 151187 ============ ======
EE 158175 AO-E1006 N143T 1.1 7/8" 575 3 CL00A310T-1 151275 1.0 1.5 RTA1-G 151187 ============ ======
EE
1.5
105662 AO-E104 P145T 4.5 7/8" 208 3 CL00A310T-1 151275 4.0 6.3 RTA1-L 151191 ============ ======
EE 159329 AO-E1016 145T 3.9 7/8" 240 3 CL00A310T-1 151275 2.5 4.1 RTA1-K 151190 ============ ======
EE 159329 AO-E1016 145T 2.0 7/8" 480 3 CL00A310T-1 151275 1.9 2.7 RTA1-J 151189 ============ ======
EE 158162 AO-E1007 R145T 1.6 7/8" 575 3 CL00A310T-1 151275 1.3 1.9 RTA1-H 151188 ============ ======
EE
2
105664 AO-E105 P145T 6.0 7/8" 208 3 CL00A310T-1 151275 4.0 6.3 RTA1-L 151191 ============ ======
EE 159027 AO-E1017 145T 5.8 7/8" 240 3 CL00A310T-1 151275 4.0 6.3 RTA1-L 151191 ============ ======
EE 159027 AO-E1017 145T 2.9 7/8" 480 3 CL00A310T-1 151275 2.5 4.1 RTA1-K 151190 ============ ======
EE 158176 AO-E1008 P145T 2.1 7/8" 575 3 CL00A310T-1 151275 1.9 2.7 RTA1-J 151189 ============ ======
EE
3
159186 B-35L405S489G3 145T 8.3 7/8" 208 3 CL00A310T-1 151275 8.0 12.0 RTA1-N 151193 ============ ======
EE 159028 B-EM3158T 145T 7.4 7/8" 240 3 CL00A310T-1 151275 5.5 8.5 RTA1-M 151192 ============ ======
EE 159028 B-EM3158T 145T 3.7 7/8" 480 3 CL00A310T-1 151275 2.5 4.1 RTA1-K 151190 ============ ======
EE 159030 B-35L405S709G1 145T 3.0 7/8" 575 3 CL00A310T-1 151275 2.5 4.1 RTA1-K 151190 ============ ======
EE
5
159029 AO-E204 H182T 13.9 1-1/8" 208 3 CL02A310T-1 151277 10.0 16.0 RTA1-P 151194 ============ ======
EE 159029 AO-E204 H182T 11.6 1-1/8" 240 3 CL01A310T-1 151276 10.0 16.0 RTA1-P 151194 ============ ======
EE 159029 AO-E204 H182T 5.8 1-1/8" 480 3 CL00A310T-1 151275 5.5 8.5 RTA1-M 151192 ============ ======
EE 111602 BAL-M3613T-5 184T 4.8 1-1/8" 575 3 CL00A310T-1 151275 4.0 6.3 RTA1-L 151191 ============ ======
EE
7.5
159331 AO-E316 D213T 22.3 1-3/8" 208 3 CL04A310M-1 151279 21.0 26.0 RTA1-U 151198 ============ ======
EE 159332 AO-E317 D213T 19.4 1-3/8" 240 3 CL25A310T-1 151278 17.5 22.0 RTA1-T 151197 ============ ======
EE 159332 AO-E317 D213T 9.7 1-3/8" 480 3 CL00A310T-1 151275 8.0 12.0 RTA1-N 151193 ============ ======
EE 158164 AO-E324 S213T 7.8 1-3/8" 575 3 CL00A310T-1 151275 5.5 8.5 RTA1-M 151192 ============ ======
EE
10
159334 AO-E397 H215T 27.8 1-3/8" 208 3 CL04A310M-1 151279 25.0 32.0 RTA1-V 151199 ============ ======
EE 159334 AO-E397 H215T 24.2 1-3/8" 240 3 CL04A310M-1 151279 21.0 26.0 RTA1-U 151198 ============ ======
EE 159334 AO-E397 H215T 12.1 1-3/8" 480 3 CL01A310T-1 151276 10.0 16.0 RTA1-P 151194 ============ ======
EE 158163 AO-E325 S215T 10.4 1-3/8" 575 3 CL01A310T-1 151276 10.0 16.0 RTA1-P 151194 ============ ======
EE
15
142440 B-EFM2513T-8 254T 41.5 1-5/8" 208 3 1.2 84 92.4% CL06A311M-1 203687 30.0 43.0 RTA2-E 151206 ============ ======
EE 142441 B-EFM2513T 254T 36.0 1-5/8" 240 3 1.2 84 92.4% CL06A311M-1 203687 30.0 43.0 RTA2-E 151206 ============ ======
EE 142441 B-EFM2513T 254T 18.0 1-5/8" 480 3 1.2 84 92.4% CL25A310T-1 151278 17.5 22.0 RTA1-T 151197 ============ ======
EE 142289 B-EFM2513T-5-F2 254T 16 1-5/8" 575 3 1.2 84 92.4% CL02A310T-1 151277 10.0 16.0 RTA1-P 151194 ============ ======
EE
20
159187 C-E452-F2 S256T 57.0 1-5/8" 208 3 1.2 84 93.6% CL07A311M-1 203793 54.0 65.0 RTA2-H 151203 ============ ======
EE 142299 B-EFM2515T 256T 48.0 1-5/8" 240 3 1.2 84 93.0% CL07A311M-1 203793 42.0 55.0 RTA2-G 151202 ============ ======
EE 142299 B-EFM2515T 256T 24.0 1-5/8" 480 3 1.2 84 93.0% CL04A310M-1 151279 21.0 26.0 RTA1-U 151198 ============ ======
EE 142300 B-EFM2515T-5 256T 19.2 1-5/8" 575 3 1.2 84 93.0% CL25A310T-1 151278 17.5 22.0 RTA1-T 151197 ============ ======
CODE 48 - 2-Speed Blower Motor CODE 49
Starter
Reznor ®
P/N
HP
Motor
Frame
Shaft
Dia Mfr No.
Overload
Mfr
No.
Reznor ®
P/N
V PH High
Speed
Low
Speed
7.5-3.3 Y215T 1 3/8 MAGN 21.6 13.6 M317 105872 208 3 222185
7.5-3.3 Y215T 1 3/8 MAGN 19.5 12.3 M317 105872 240 3 114982
7.5-3.3 D215T 1 3/8 MAGN 10 6 M315 105873 480 3 114983
10-4.4 S256T 1 5/8 MAGN 31 19.4 M421 105874 208 3 222186
10-4.4 S256T 1 5/8 MAGN 28 17.5 M421 105874 240 3 114984
10-4.4 S256T 1 5/8 MAGN 13.5 7.5 M413 105875 480 3 114985
15-6.7 S284T 1.9 MAGN 47 22 M521 165726 208 3 165733
15-6.7 S284T 1.9 MAGN 54 21 M521 165726 230 3 165736
15-6.7 S256T 1.6 MAGN 20 10.5 M423 165727 460 3 165734
20-8.9 S286T 1.9 MAGN 56 29 M522 165728 208 3 165735
20-8.9 S286T 1.9 MAGN 51 27 M522 165728 230 3 165736
20-8.9 S286T 1.9 MAGN 24 12 M504 165729 460 3 165737
Two-Speed Motors and Starters
CODE 48 - 2-Speed Blower Motor CODE 49
Starter
Reznor ®
P/N
HP
Motor
Frame
Shaft
Dia Mfr No.
Overload
Mfr
No.
Reznor ®
P/N
V PH High
Speed
Low
Speed
1-.44 M145T 7/8 MAGN 3.8 2.4 M124 105641 208 3 222180
1-.44 M145T 7/8 MAGN 3.4 2.2 M124 105641 240 3 114971
1-.44 M145T 7/8 MAGN 1.7 1.1 M109 105642 480 3 114972
1.5-.68 N145T 7/8 MAGN 5.4 3.1 M125 105643 208 3 222181
1.5-.68 N145T 7/8 MAGN 4.9 2.8 M125 105643 240 3 114973
1.5-.68 N145T 7/8 MAGN 2.4 1.4 M104 105644 480 3 114974
2-.88 S182T 1 1/8 MAGN 6.5 4.2 M220 105645 208 3 222182
2-.88 S182T 1 1/8 MAGN 5.9 3.8 M220 105645 240 3 114976
2-.88 S182T 1 1/8 MAGN 3.4 2.1 M207 105646 480 3 114977
3-1.3 S184T 1 1/8 MAGN 9.3 5.3 M221 105647 208 3 222183
3-1.3 S184T 1 1/8 MAGN 8.4 4.8 M221 105647 240 3 114978
5-2.2 S215T 1 3/8 MAGN 15.5 10.2 M320 105870 240 3 114980
5-2.2 S215T 1 3/8 MAGN 7.1 4.8 M305 105871 480 3 114981 N.O. Auxiliary Contacts, 690V, P/N 115951; N.C. Auxiliary Contacts, 690V, P/N 115952
