Reznor RDF Parts Manuals - Manual (Page 25)

Form P-RDF, P/N 270069 R6, Page 25
Model RDF 2-80 with a CLASS 2 BLOWER (cont'd)
Open Motor Horz/Vert
Discharge
Drive Option
(See page 21.)
CODE 200 - Motor Sheave CODE 201 - Blower Sheave CODE 202 - Belt CODE 203
- Bushing HP Option P/N Mfr No. Bore P/N Mfr No. Bore P/N Qty Mfr No.
7-1/2
AL11 V AM10-11 16150
2VP62
1-3/8
114045 2BV110
1-7/16
92280 2 BX59 114033
AL11 H AM10-11 16150 114045 92409 2 BX55 114033
AL11 V AM12-15 106257
2VP60
113804 2BK90H 92222 2 B53 89659
AL11 H AM12-15 106257 113804 92220 2 B51 89659
10
AL12 V AM6-7 113802 2VP68
1-3/8
89651 2BK160H
1-7/16
114104 2 B66 89659
AL12 H AM6-7 114249 2VP71 89651 92414 2 B64 89659
AL12 V AM8-9 106257
2VP60
113811 2BK120H 92226 2 B58 89659
AL12 H AM8-9 106257 113811 92224 2 B56 89659
AL12 V AM10-11 16150
2VP62
114045 2BV110 92280 2 BX59 114033
AL12 H AM10-11 16150 114045 92409 2 BX55 114033
AL12 V AM12-15 106257
2VP60
113804 2BK90H 92222 2 B53 89659
AL12 H AM12-15 106257 113804 92220 2 B51 89659
15
AL15 V AM7-9 91615 2MVP40B54
1-5/8
113811 2BK120H
1-7/16
92409 2 BX55 89659
AL15 H AM7-9 113809
2VP71A
92204 2BK140H 16143 2 B59 89659
AL15 V AM10-11 113809 89650 2BK130H 92226 2 B58 89659
AL15 H AM10-11 113809 89650 92225 2 B57 89659
AL15 V AM12-16 114047 2MVP45B59 114048
2B5V86
92236 2 BX50 114033
AL15 H AM12-16 114047 114048 113805 2 B49 114033
AL15 V AM17-20 113808
2VP75
114048 114341 2 BX53 114033
AL15 H AM17-20 113808 114048 92237 2 BX51 114033
TEFC Motor Horz/Vert-
Discharge
Drive Option
(See page 21.)
CODE 200 - Motor Sheave CODE 201 - Blower Sheave CODE 202 - Belt CODE 203
- Bushing HP Option P/N Mfr No. Bore P/N Mfr No. Bore P/N Qty Mfr No.
5 AL27 H AM7-9 111681 1VP50 1-1/8 113799 AK184H 1-7/16 16139 2 A67 89659
NOTE: If drive components are required for units with a TEFC motor not listed here, contact your Distributor or the Factory Service Department. Be
prepared to provide complete Model and Serial No.
Model RDF-2-80 with a Class 1 Blower [Effective 8/90 (Serial No. Code APH) all RDF-2-80 Models are equipped with a
Class 2 blower. For Model RDF-2-80 with a Class 2 blower, see table above. A Class 2 blower was an available option prior to 8/90.
Motor
AM No. (See
page 21.
Blower RPM
Range
Motor Sheave Blower Sheave Blower Bushing Discharge
H=Horizontal
V=Vertical
Belt
HP
Option
No.
P/N Mfr No. P/N Mfr No. P/N Size P/N Size Qty
2 AL8
3 501-550 13013 1VP50 (5/8) 92416 AK134 92203 H-1"
H 92402 A59 1
V 80838 A77 1
4 551-600 13013 1VP50 (5/8) 92417 AK124 92203 H-1"
H 16134 A57 1
V 92403 A76 1
5 601-650 13013 1VP50 (5/8) 92418 AK114 92203 H-1"
H 16133 A56 1
V 92404 A74 1
3 and 5
AL9,
AL10
3 501-550 7963
2VP42
(1-1/8)
91621 2TB200 6605 Q-1"
H 80839 A72 2
V 92406 A89 2
4 551-600 7963
2VP42
(1-1/8)
92208 2TB184 6605 Q-1"
H 16558 A69 2
V 92219 A86 2
5 601-650 7963
2VP42
(1-1/8)
92208 2TB184 6605 Q-1"
H 16558 A69 2
V 92219 A86 2
6 651-700 7963
2VP42
(1-1/8)
92206 2TB154 6605 Q-1"
H 16138 A63 2
V 92217 A81 2
7 701-750 7963
2VP42
(1-1/8)
92206 2TB154 6605 Q-1"
H 16138 A63 2
V 92217 A81 2
8 751-800 7963
2VP42
(1-1/8)
92204 2BK140 92203 H-1"
H 92402 A59 2
V 80838 A77 2
9 801-850 7963
2VP42
(1-1/8)
92204 2BK140 92203 H-1"
H 92402 A59 2
V 80838 A77 2
10 851-900 7963
2VP42
(1-1/8)
89650 2BK130 92203 H-1"
H 16134 A57 2
V 92403 A76 2
11 901-950 7963
2VP42
(1-1/8)
89650 2BK130 92203 H-1"
H 16134 A57 2
V 92403 A76 2
7.5 AL11
6 651-700 89641 2MVP40B546
(1-3/8)
39458 2TB124 6605 Q-1"
H 7972 B60 2
V 92234 B78 2
7 701-750 89641 2MVP40B546
(1-3/8)
91631 2TB110 6605 Q-1"
H 92225 B57 2
V 92232 B76 2
8 751-800 89641 2MVP40B546
(1-3/8)
91631 2TB110 6605 Q-1"
H 92225 B57 2
V 92232 B76 2
9 801-850 89641 2MVP40B546
(1-3/8)
91632 2TB94 6605 Q-1"
H 92223 B54 2
V 92230 B73 2
10 851-900 89641 2MVP40B546
(1-3/8)
91632 2TB94 6605 Q-1"
H 92223 B54 2
V 92230 B73 2
11 901-950 89641 2MVP40B546
(1-3/8)
91633 2TB86 6605 Q-1"
H 92222 B53 2
V 92229 B71 2
12 951-1000 89641 2MVP40B546
(1-3/8)
91633 2TB86 6605 Q-1"
H 92222 B53 2
V 92229 B71 2
13 1001-1050 89641 2MVP40B546
(1-3/8)
92205 2TB74 6605 Q-1"
H 92220 B51 2
V 92228 B70 2
10 AL12
7 701-750 89641 2MVP40B546
(1-3/8)
91631 2TB110 6605 Q-1"
H 92225 B57 2
V 92232 B76 2
8 751-800 89641 2MVP40B546
(1-3/8)
91631 2TB110 6605 Q-1"
H 92225 B57 2
V 92232 B76 2
