Reznor RDF Parts Manuals - Manual (Page 30)

Form P-RDF, P/N 270069 R6, Page 30
Filter Rack Assembly w/1" Filters for RDF-2,
Opt AW3, Pkg P/N 68775
Filter Rack Assembly w/2" Filters for RDF-2,
Opt AW6, Pkg P/N 72626
P/N Component Description Qty P/N Component Description Qty
89982 Fltr Channel Top/Btm Assy Rdf2 3 89986 Top Filter Blockoff Plate Rdf2 1
89983 Fltr Channel Top/Btm Rdf-2 2 258249 Btm Fltr Block Off Plate Rdf-2 1
89986 Top Filter Blockoff Plate Rdf2 1 89988 Filter Door Rdf-2 2
258249 Btm Fltr Block Off Plate Rdf-2 1 89989 Fltr Cab Rt Rear Corner Rdf-2 2
89988 Filter Door Rdf-2 2 89990 Fltr Cab Rt Corner Rdf-2 2
89989 Fltr Cab Rt Rear Corner Rdf-2 2 89991 Fltr Cab Bottom Pan Rdf-2 1
89990 Fltr Cab Rt Corner Rdf-2 2 89992 Fltr Cab Top Rdf-2 1
89991 Fltr Cab Bottom Pan Rdf-2 1 94221 Filter Channel T/B Assy Rdf2 3
89992 Fltr Cab Top Rdf-2 1 94222 Filter Channel Top/Bot 2" Rdf2 2
114335 Filter Block Off Plate 4 94382 Perm Aluminum Filter 12x24x2" 4
87251 Perm Alum Filter 12X35X1 4 94383 Perm Aluminum Filter 12x35x2" 4
89353 Perm Alum Filter 12X24X1 4 114336 Filter Blockoff Plate 4
11813 S/M Screw #10-16x1/2 54 11813 S/M Screw #10-16x1/2 54
CODE 270 (cont'd) - Screened Air Inlet Hoods for Outdoor Units and Filter Sections for Indoor Units
Outside Air Hood for RDF-3,
Opt AS2, Pkg P/N 71150
Outside Air Hood w/Filter Rack & 1"
Permanent Filters for RDF-3, Opt AS6, Pkg
P/N 71152
Outside Air Hood w/Filter Rack & 2"
Permanent Filters for RDF-3, Opt AS7, Pkg
P/N 72627
P/N Components Qty P/N Component Description Qty P/N Component Description Qty
91567 Hood Bottom RDF3 1 91567 Hood Bottom RDF3 1 91567 Hood Bottom RDF3 1
91568 Hood Lt Side RDF3 1 91568 Hood Lt Side RDF3 1 91568 Hood Lt Side RDF3 1
91569 Hood Rt Side RDF3 1 91569 Hood Rt Side RDF3 1 91569 Hood Rt Side RDF3 1
91575 Hood Top Front RDF3 1 91575 Hood Top Front RDF3 1 91575 Hood Top Front RDF3 1
91576 Hood Top Rear RDF3 1 91576 Hood Top Rear RDF3 1 91576 Hood Top Rear RDF3 1
91577 Top Clamp RDF3 1 91577 Hood Top Clamp RDF3 1 91577 Hood Top Clamp RDF3 1
91578 Intermediate Post RDF3 2 91578 Intermediate Post RDF3 2 91578 Intermediate Post RDF3 2
91579 Rt/Lt Corner RDF3 2 91579 Rt/Lt Corner RDF3 2 91579 Rt/Lt Corner RDF3 2
91581 Support 6 91580 Fltr Chnl Top/Bottom RDF3 2 91581 Support 6
272444 Rt Side Fltr Support 2 91581 Support 6 272444 Rt Side Fltr Support RDF3 2
91585 Filter Door RDF3 2 272444 Rt Side Fltr Support RDF3 2 91585 Filter Door RDF3 2
113003 Louver Rack Assy 2 91584 Block Off Plate RDF3 2 94223 2" Fltr Chnl Top/Btm Assy RDF3 5
7328 Nut, Hex 1/4-20 Keps 15 91585 Filter Door RDF3 2 94224 Fltr Chnl Top/Btm 2 In RDF-3 2
10393 1/4 - 20 X 5/8" Hwhsltrs Z 15 91586 Filter Channel Top/Btm Assy 5 94383 Perm Alum Filter 12x35x2" 10
11813 S/M Screw #10-16x1/2 100 113003 Louver Rack Assy 2 98764 Bottom Filter Block Off Plate 2
37661 Screw,Teks, #10-16x1/2,S/Drill 4 263784 Filter Block-Off Plate RDF3 6 113003 Louver Rack Assy 2
41463 14 X 3/4" Hwslsms Abz Screw 3 87251 Perm Alum Filter 12X35X1 12 263784 Filter Block-Off Plate RDF3 5
87900 Palnut #Pw-1880-008-21 5 1849 Nuts #C7392-110z-1 5 1849 Nuts #C7392-110z-1 5
7328 Nut, Hex 1/4-20 Keps 15 7328 Nut, Hex 1/4-20 Keps 15
10393 1/4 - 20 X 5/8" Hwhsltrs Z 15 10393 1/4 - 20 X 5/8" Hwhsltrs Z 15
11813 S/M Screw #10-16x1/2 100 11813 S/M Screw #10-16x1/2 100
37661 Screw,Teks, #10-16x1/2,S/Drill 4 37661 Screw,Teks, #10-16x1/2,S/Drill 4
41463 14 X 3/4" Hwslsms Abz Screw 3 41463 14 X 3/4" Hwslsms Abz Screw 3
Filter Rack Assembly w/1" Filters for RDF-3,
Opt AW3, Pkg P/N 71153
Filter Rack Assembly w/2" Filters for RDF-3,
Opt AW6, Pkg P/N 72628
P/N Component Description Qty P/N Component Description Qty
91567 Hood Bottom RDF3 1 91567 Hood Bottom RDF3 1
91579 Hood Rt/Lt Corner RDF3 2 91579 Hood Rt/Lt Corner RDF3 2
91580 Fltr Chnl Top/Bottom RDF3 2 91583 Fltr Cab Duct Angle RDF3 1
91584 Block Off Plate RDF3 2 91585 Filter Door RDF3 2
91585 Filter Door RDF3 2 91587 Fltr Cab Lt/Rt Rear Crnr RDF3 2
91586 Channel Top/Btm Assy RDF3 5 91590 Fltr Cab Top RDF3 1
91587 Fltr Cab Lt/Rt Rear Crnr RDF3 2 94223 2" Fltr Chnl Top/Btm Assy RDF3 4
91590 Fltr Cab Top RDF3 1 94224 Fltr Chnl Top/Btm RDF-3 2
263784 Filter Block-Off Plate RDF3 6 94383 Perm Alum Filter 12x35x2" 10
87251 Perm Alum Filter 12X35X1 12 98764 Bottom Filter Block Off Plate 2
11813 S/M Screw #10-16x1/2 64 263784 Filter Block-Off Plate RDF3 5
11813 S/M Screw #10-16x1/2 50
