Form P-RDF, P/N 270069 R6, Page 29

CODE 270 - Screened Air Inlet Hoods for Outdoor Units and Filter Sections for Indoor Units

Description (See component lists below)

RDF-1 RDF-2 RDF-3

100% Outside Air Inlet Hood (Same as Option AS2)

69594 68774 71150

100% Outside Air Inlet Hood w/Integral Filter Rack & 1" Permanent Filters (Same as Option AS6) 69596 68739 71152

100% Outside Air Inlet Hood with Integral Filter Rack & 2" Permanent Filters (Same as Option AS7) 72623 72625 72627

Outside Air Filter Section for Indoor Units with 1" Filters (Same as Option AW3)

69597 68775 71153

Outside Air Filter Section for Indoor Units with 2" Filters (Same as Option AW6)

72624 72626 72628

Outside Air Hood for RDF-1,

Opt AS2, Pkg P/N 69594

Outside Air Hood w/Filter Rack & 1" Permanent

Filters for RDF-1, Opt AS6, Pkg P/N 69596

Outside Air Hood w/Filter Rack & 2" Permanent

Filters for RDF-1, Opt AS7, Pkg P/N 72623

P/N Components

Qty

P/N Component Description

Qty

P/N Component Description

Qty

87520 Hood Top

1

87520 Weather Hood Top

1

87520 Weather Hood Top

1

87522 Hood Left Side

1

87521 Filter Adapter Side

1

87521 Filter Adapter Side

1

87523 Hood Right Side

1

87522 Hood Left Side

1

87522 Hood Left Side

1

87525 Louver Left Side

1

87525 Louver Left Side

1

87525 Louver Left Side

1

87526 Louver Right Side

1

87526 Louver Right Side

1

87526 Louver Right Side

1

87527 Louver

11

87527 Louver

11

87527 Louver

11

87529 Screen Angle

2

87529 Screen Angle

2

87529 Screen Angle

2

87530 Hood Bottom

1

87530 Hood Bottom

1

87530 Hood Bottom

1

87528 Screen 39X35-1/4

1

87531 Hood Right Corner-

1

87531 Hood Right Corner-

1

11813 S/M Screw #10-16x1/2 34

87532 Filter Chnnl Top/Btm Assy

2

87534 Right Side Filter Angle

1

87533 Filter Channel Top/Btm

2

87535 Right Side Filter Support

1

87534 Right Side Filter Angle

1

87536 Top Filter Block Off Plate

1

87535 Right Side Filter Support

1

87538 Filter Door

1

87536 Top Filter Block Off Plate

1

94137 Filter Channel Top/Bot 2"

2

87537 Btm Filter Block Off Plate

1

94220 Filter Channel Top/Btm Assy

2

87538 Filter Door

1

94383 Perm Alum Filter 12x35x2

3

87528 Screen 39X35-1/4

1

87528 Screen 39X35-1/4

1

11813 S/M Screw #10-16x1/2

54

11813 S/M Screw #10-16x1/2

54

87251 Perm Alum Filter 12X35X1

3

Filter Rack Assembly w/1" Filters for RDF-1,

Opt AW3, Pkg P/N 69597

Filter Rack Assembly w/2" Filters for RDF-1,

Opt AW6, Pkg P/N 72624

P/N

Component Description

Qty

P/N

Component Description

Qty

87532 Filter Channel Top/Btm Assy

2

87536 Top Filter Block Off Plate

1

87533 Filter Channel Top/Btm

2

87538 Filter Door

2

87538 Filter Door

2

87859 Fltr Cab Right Rear Corner

2

87859 Fltr Cab Right Rear Corner

2

87860 Filter Cabinet Rght Corner

2

87860 Filter Cabinet Right Corner

2

87861 Filter Cabint Bottom Panel

1

87861 Filter Cabinet Btm Panel

2

87862 Filter Cabinet Top

1

87862 Filter Cabinet Top

1

94137 Filter Channel Top/Bot 2"

2

87251 Perm Alum Filter 12X35X1

3

94220 Filter Channel Top/Btm Assy

2

11813 S/M Screw #10-16x1/2

44

94383 Perm Alum Filter 12x35x2

3

11813 S/M Screw #10-16x1/2

44

Outside Air Hood for RDF-2,

Opt AS2, Pkg P/N 68774

Outside Air Hood w/Filter Rack & 1" Permanent

Filters for RDF-2, Opt AS6, Pkg P/N 68739

Outside Air Hood w/Filter Rack & 2" Permanent

Filters for RDF-2, Opt AS7, Pkg P/N 72625

P/N Components

Qty

P/N Component Description

Qty

P/N Component Description

Qty

89972 Hood Bottom

1

89972 Hood Bottom RDF-2

1

89972 Hood Bottom RDF-2

1

89975 Louver Left Side

1

89975 Louver Left Side RDF-2

1

89975 Louver Left Side RDF-2

1

89976 Louver Right Side

1

89976 Louver Right Side RDF-2

1

89976 Louver Right Side RDF-2

1

89977 Louvers

14

89977 Louvers RDF-2

14

89977 Louvers RDF-2

14

89978 Screen

1

89978 Screen RDF-2

1

89978 Screen RDF-2

1

89979 Screen Angle

1

89979 Screen Angle

1

89979 Screen Angle

1

89980 Filter Adapter Right

1

89980 Filter Adapter Right RDF-2

1

89980 Filter Adapter Right RDF-2

1

89981 Right Corner

1

89981 Rightt Corner RDF-2

1

89981 Right Corner RDF-2

1

89988 Filter Door

2

89982 Fltr Channel Top/Btm Assy

3

89986 Top Filter Blockoff Plate

1

90220 Top Front

1

89983 Fltr Channel Top/Btm RDF-2

2

258249 Btm Flilter Block Off Plate

1

90221 Top Rear

1

89986 Top Filter Blockoff Plate

1

89988 Filter Door RDF-2

2

90222 Top Clamp

1

258249 Btm Filter Blockoff Plate

1

90220 Hood Top Front RDF-2

1

91581 Support

6

89988 Filter Door RDF-2

2

90221 Hood Top Rear RDF-2

1

95279 Left Corner

1

90220 Hood Top Front RDF-2

1

90222 Hood Top Clamp RDF-2

1

95280 Filter Adapter Left

1

90221 Hood Top Rear RDF-2

1

91581 Support

6

7328 Nut, Hex 1/4-20 Keps 6

90222 Hood Top Clamp RDF-2

1

94221 Filter Channel Top/Btm Assy

3

10393 1/4-20X5/8" Hwhsltrs Z 6

91581 Support

6

94222 Filter Channel Top/Bot 2"

2

11813 S/M Screw #10-16x1/2 44

95279 Left Corner

1

95279 Left Corner

1

41463 14 X 3/4" Hwslsms Abz

Screw

3

95280 Filter Adapter Left

1

95280 Filter Adapter Left

1

7328 Nut, Hex 1/4-20 Keps

9

94382 Perm Aluminum Filter 12x24x2"

4

10393 1/4 - 20 X 5/8" Hwhsltrs Z

9

94383 Perm Aluminum Filter 12x35x2"

4

11813 S/M Screw #10-16x1/2 Ab Stalgd

64

7328 Nut, Hex 1/4-20 Keps

6

41463 14 X 3/4" Hwslsms Abz Screw

3

10393 1/4 - 20 X 5/8" Hwhsltrs Z

6

87251 Perm Alum Filter 12X35X1

4

11813 S/M Screw #10-16x1/2

64

89353 Perm Alum Filter 12X24X1

4
