Form P-RDF, P/N 270069 R6, Page 26
Drive Components (cont'd)
Model RDF 2-120
* Open Motor Horz/Vert
Discharge
Drive Option
(See page 21.)
CODE 200 - Motor Sheave CODE 201 - Blower Sheave CODE 202 - Belt CODE 203 -
Bushing HP Option P/N Mfr No. Bore P/N Mfr No. Bore P/N Qty Mfr No.
2
2 HP Drive Components for Model RDF 2-120 Series 3 only
AL8 V AM3-5 106758 1VL44
7/8
113798 AK104H 1-7/16 16130 1 A53 89659
AL8 H AM3-5 106748 1VL40 114026 BK110H 92223 1 B54 89659
2 HP Drive Components for Model RDF 2-120 prior to Series 3
AL8 V AM3-5 105476 1VL44
5/8
113798 AK104H 1-7/16 16130 1 A53 89659
AL8 H AM3-5 7962 1VL40 114026 BK110H 92223 1 B54 89659
3
AL9 V AM3-4 87500
2VP36
7/8
89652 2BK10H
1-7/16
92241 2 BX68 89659
AL9 H AM3-4 87500 114027 2AK184H 16558 2 A69 89659
AL9 V AM5-7 106758 1VL44 113799 AK184H 16558 1 A69 89659
AL9 H AM5-7 110125 1VP34 114028 AK134H 92402 1 A59 89659
AL9 V AM8-11 106758
1VL44
113800 AK144H 88560 1 A61 89659
AL9 H AM8-11 106758 113800 AK144H 16138 1 A63 89659
5
AL10 V AM3-4 87500
2VP36
7/8
89652 2BK10H
1-7/16
92241 2 BX68 89659
AL10 H AM3-4 87500 114027 2AK184H 16558 2 A69 89659
AL10 V AM5-7 87500 89651 BK160H 92411 2 BX62 89659
AL10 H AM5-7 6599 2VP42 114027 2AK184H 114257 2 A70 89659
AL10 V AM8-11 87500
2VP36
113801 2AK104H 16130 2 A53 89659
AL10 H AM8-11 87500 114034 2AK124H 16134 2 A57 89659
7-1/2
AL11 V AM4-5 110771
2VP65
1-3/8
114032 2B5V160
1-7/16
114258 2 BX64 114033
AL11 H AM4-5 110771 114032 2B5V160 80841 2 BX67 114033
AL11 V AM6-7 113802 2VP68 89651 2BK160H 92278 2 BX63 89659
AL11 H AM6-7 114249 2VP71 89651 2BK160H 114104 2 B66 89659
AL11 V AM8-11 106257
2VP60
113803 2BK110H 92223 2 B54 89659
AL11 H AM8-11 106257 113803 2BK110H 92224 2 B56 89659
AL11 V AM12-15 106257 113804 2BK90H 114010 2 B50 89659
AL11 H AM12-15 106257 113804 2BK90H 92222 2 B53 89659
10
AL12 V AM4-5 110771
2VP65
1-3/8
114032 2B5V160
1-7/16
114258 2 BX64 114033
AL12 H AM4-5 110771 114032 2B5V160 80841 2 BX67 114033
AL12 V AM6-7 113802 2VP68 89651 2BK160H 92278 2 BX63 89659
AL12 H AM6-7 114249 2VP71 89651 2BK160H 114104 2 B66 89659
AL12 V AM8-11 106257
2VP60
113803 2BK110H 92223 2 B54 89659
AL12 H AM8-11 106257 113803 2BK110H 92224 2 B56 89659
AL12 V AM12-15 106257 113804 2BK90H 114010 2 B50 89659
AL12 H AM12-15 106257 113804 2BK90H 92222 2 B53 89659
15
AL15 V AM6-7 113808 2VP75
1-5/8
114032 2B5V160
1-7/16
92411 2 BX62 114033
AL15 H AM6-7 91615 2MVP40B54 113811 2BK120H 92409 2 BX55 89659
AL15 V AM8-9 113809 2VP71A 92204 2BK140H 92226 2 B58 89659
AL15 H AM8-9 91615 2MVP40B54 113811 2BK120H 92409 2 BX55 89659
AL15 V AM10-11 113808 2VP75 89650 2BK130H 92224 2 B56 89659
AL15 H AM10-11 113809 2VP71A 89650 16143 2 B59 89659
AL15 V AM12-13 113808
2VP75
113811 2BK120H 112531 2 B55 89659
AL15 H AM12-13 113808 113811 92226 2 B58 89659
* If drive components are required for units with a 3-10HP TEFC or 3-10 HP Premium Efficiency motor, contact your Distributor or the
Factory Service Department. Be prepared to provide complete Model and Serial No.
Model RDF 3-180
*Open Motor Blower
Class
Horz/Vert
Discharge
Drive Option
(See page
21.)
CODE 200 - Motor Sheave CODE 201- Blower Sheave CODE 202 - Belt CODE
203 -
Bushing
HP Option P/N Mfr No. Bore P/N Mfr No. Bore P/N Qty Mfr No.
5
AL10 1 V AM2-3 6599 2VP42
7/8
115718 2B5V250
1-7/16
92319 2 BX97 114033
AL10 1 V AM4-5 87500 2VP36 89652 2BK190H 92312 2 B86 89659
AL10 1 H AM2-3 6599 2VP42 115718 2B5V250 92308 2 B92 114033
AL10 1 H AM4-5 87500 2VP36 89652 2BK190H 92341 2 BX77 89659
7-1/2
and
10
AL11/12 1 V AM1 114249 2VP71
1-3/8
115718 2B5V250
1-7/16
115932 2 BX99 114033
AL11/12 1 V AM2 106257 2VP60 89652 2BK190H 115933 2 B88 89659
AL11/12 1 V AM3 16150 2VP62 89652 115934 2 B89 89659
AL11/12 1 V AM4-5 110771 2VP65 114032 2B5V160 92273 2 B84 114033
AL11/12 1 V AM6-7 114249 2VP71 114032 92317 2 BX85 114033
AL11/12 1 V AM8-9 106257 2VP60 113811 2BK120H 92277 2 BX75 89659
AL11/12 1 H AM1 114249 2VP71 115718 2B5V250 92313 2 BX93 114033
AL11/12 1 H AM2 106257 2VP60 89652 2BK190H 92332 2 BX79 89659
AL11/12 1 H AM3 16150 2VP62 89652 92332 2 BX79 89659
AL11/12 1 H AM4-5 110771 2VP65 114032 2B5V160 92277 2 BX75 114033
AL11/12 1 H AM6-7 114249 2VP71 89651 92277 2 BX75 89659
AL11/12 1 H AM8-9 106257 2VP60 113811 2BK120H 92240 2 BX66 89659
15
and
20
AL15/16 1 V AM4-5 89644 3MVP40B54
1-5/8
115720 3B5V136
1-7/16
92341 3 BX77 114033
AL15/16 1 V AM6-7 115719 3MVP50B64 115721 3B5V154 92274 3 BX81 114033
AL15/16 1 V AM8-10 89645 3MVP45B59 115722 3BK120H 92231 3 B74 89659
AL15/16 1 V AM11-14 89644 3MVP40B54 115723 3BK90H 92241 3 BX68 89659
AL15/16 2 V AM2-3 89645 3MVP45B59 115943 3B5V184
2-3/16
92310 3 B87 116205
AL15/16 2 V AM4-6 89644 3MVP40B54 115720 3B5V136 92341 3 BX77 116205
