Reznor RDF Parts Manuals - Manual (Page 2)

Form P-RDF, P/N 270069 R6, Page 2
Rating Plate and Serial No.
REZNOR ®
MERCER, PA. USA 16137
ANSI Z83.4/CSA 3.7-2013 NON-RECIRCULATING DIRECT-FIRED INDUSTRIAL AIR
HEATER
ANSI Z83.4/CSA 3.7-2013 DIRECT INDUSTRIEL ONT TIRE DU RÉCHAUFFEUR D'AIR
FOR INDUSTRIAL/COMMERCIAL USE ONLY
FOR EITHER INDOOR OR OUTDOOR INSTALLATION
INSTALLER À L'INTÉRIEUR OU À L'EXTÉRIEUR
MODEL { A } SERIAL # { computer generated }
GAS TYPE{ B } MOTOR HP{ C }
VOLTAGE { D } PHASE{ E } 60 HZ
MAX TOTAL INPUT AMPS FOR THE UNIT { F }
WIRING DIAGRAM NUMBER: { P }
UNIT IS EQUIPPED FOR { G } SCFM AGAINST { H } IN WC ESP
WITH A MAX DISCH TEMP OF { Q } °F AND A MAX TEMP RISE OF
{ Z } °F AND CANNOT BE USED BELOW -40 °F
CONCU POUR { X } M 3 CONTRE UNE PRESSION STATIQU
EXTERNE DE { W } KPA (PO C.E.) WITH A MAX DISCHARGE TEMP OF
{ Y } °C AND A MAX TEMP RISE OF { AA } °C AND CANNOT BE USED BELOW -40 °C.
MAXIMUM INPUT RATING { J } BTU/HR
MINIMUM INPUT RATING ( K } BTU/HR
NORMAL MANIFOLD PRESS { L } IN WC
MIN GAS INLET PRESS. FOR BURN. ADJ. { M } IN WC
MAX PERMISSIBLE GAS SUPPLY PRESS. { N } PSI
MIN PRESSURE DROP ACROSS BURNER 0.25 IN WC
MAX PRESSURE DROP ACROSS BURNER 0.75 IN WC
MAXIMUM INPUT RATING { R } KW/HR
MINIMUM INPUT RATING { S } KW/HR
NORMAL MANIFOLD PRESS. { T } KPA
MIN GAS INLET PRESS. FOR BURN. ADJ. { U } KPA
MAX PERMISSIBLE GAS SUPPLY PRESS. { V } KPA
MIN PRESSURE DROP ACROSS BURNER 0.0625 KPA
MAX PRESSURE DROP ACROSS BURNER 0.1875 KPA
CLEARANCES TO COMBUSTIBLES: TOP, BOTTOM, AND SIDE OPPOSITE CONTROLS
- 1 INCH. FOR SERVICE ON CONTROL SIDE OF UNIT - WIDTH OF UNIT
Sample of a Rating Plate
Rating Plate Codes:
A = Model No.
B = Gas Type (Nat or LP)
C = Motor HP
D = Voltage
E = Phase
F = Maximum Total Input Amps for Unit
G = SCFM
H = ESP ("w.c.)
I = CFM
J = Maximum Input (BTU/HR)
K = Minimum Input (BTU/HR)
L = Manifold Pressure ("w.c.)
M = Minimum Inlet Pressure ("w.c.)
N = Maximum Supply Pressure (PSI.)
P = Wiring Diagram No.
Q = Maximum Discharge Temperature (°F)
R = Maximum Input (kw/HR)
S = Minimum Input (kw/HR)
T= Manifold Pressure (KPA.)
U = Minimum Inlet Pressure (KPA.)
V = Maximum Supply Pressure (KPA.)
W = ESP.(KPA)
X = M 3
Y = Maximum Discharge Temperature (°C)
Z = Maximum Temperature Rise (°F)
AA = Maximum Temperature Rise (°C)
Serial No. Example:
Codes: 1 = Date of manufacture (see chart below)
2 = Type of pilot
3 = Type of valve
4 = Type of gas (N= Natural; L= Propane)
5 = Consecutive number
6 = Type of air control (CA = Constant Air
Volume; VA = Variable Air Volume;
RA = Recirculation Air)
7 = Type of Maxitrol Gas Control - (MV7
= Maxitrol System 14; MV8 = Maxitrol
System 14A; MVC = Maxitrol A200)
BLJ 82 V1 N 12345 CA MV7
1 2 3 4 5 6 7
Year Jan Feb Mar Apr May June July Aug Sept Oct Nov Dec
1984 AJA AJB AJC AJD AJE AJF AJG AJH AJI AJJ AJK AJL
1985 AKA AKB AKC AKD AKE AKF AKG AKH AKI AKJ AKK AKL
1986 ALA ALB ALC ALD ALE ALF ALG ALH ALI ALJ ALK ALL
1987 AMA AMB AMC AMD AME AMF AMG AMH AMI AMJ AMK AML
1988 ANA ANB ANC AND ANE ANF ANG ANH ANI ANJ ANK ANL
1989 AOA AOB AOC AOD AOE AOE AOG AOH AOI AOJ AOK AOL
1990 APA APB APC APD APE APF APG APH API APJ APK APL
1991 AQA AQB AQC AQD AQE AQF AQG AQH AQI AQJ AQK AQL
1992 ARA ARB ARC ARD ARE ARF ARG ARH ARI ARJ ARK ARL
1993 ASA ASB ASC ASD ASE ASF ASG ASH ASI ASJ ASK ASL
1994 ATA ATB ATC ATD ATE ATF ATG ATH ATI ATJ ATK ATL
1995 AUA AUB AUC AUD AUE AUF AUG AUH AUI AUJ AUK AUL
1996 AVA AVB AVC AVD AVE AVF AVG AVH AVI AVJ AVK AVL
1997 AWA AWB AWC AWD AWE AWF AWG AWH AWI AWJ AWK AWL
1998 AXA AXB AXC AXD AXE AXF AXG AXH AXI AXJ AXK AXL
1999 AYA AYB AYC AYD AYE AYF AYG AYH AYI AYJ AYK AYL
2000 AZA AZB AZC AZD AZE AZF AZG AZH AZI AZJ AZK AZL
2001 BAA BAB BAC BAD BAE BAF BAG BAH BAI BAJ BAK BAL
2002 BBA BBB BBC BBD BBE BBF BBG BBH BBI BBJ BBK BBL
2003 BCA BCB BCC BCD BCE BCF BCG BCH BCI BCJ BCK BCL
2004 BDA BDB` BDC BDD BDE BDF BDG BDH BDI BDJ BDK BDL
2005 BEA BEB BEC BED BEE BEF BEG BEH BEI BEJ BEK BEL
2006 BFA BFB BFC BFD BFE BFF BFG BFH BFI BFJ BFK BFL
2007 BGA BGB BGC BGD BGE BGF BGG BGH BGI BGJ BGK BGL
2008 BHA BHB BHC BHD BHE BHF BHG BHH BHI BHJ BHK BHL
2009 BIA BIB BIC BID BIE BIF BIG BIH BII BIJ BIK BIL
2010 BJA BJB BJC BJD BJE BJF BJG BJH BJI BJJ BJK BJL
2011 BKA BKB BKC BKD BKE BKF BKG BKH BKI BKJ BKK BKL
2012 BLA BLB BLC BLD BLE BLF BLG BLH BLI BLJ BLK BLL
2013 BMA BMB BMC BMD BME BMF BMG BMH BMI BMJ BMK BML
2014 BNA BNB BNC BND BNE BNF BNG BNH BNI BNJ BNK BNL
2015 BOA BOB BOC BOD BOE BOF BOG BOH BOI BOJ BOK BOL
First Element of the Serial Number - Date of Manufacture
