Form P-RDF, P/N 270069 R6, Page 24
Drive Components (cont'd)
Model RDF 1-50 (cont'd)
Open Motor Horz/Vert
Discharge
Drive Option
(See page 21.)
CODE 200 - Motor Sheave CODE 201- Blower Sheave CODE 202 - Belt
HP Option P/N Mfr No. Bore P/N Mfr No. Bore P/N Mfr No.
3
AL9 V AM8-11 106758
1VL44
7/8
113372
AK144
1
88560 A61
AL9 H AM8-11 106758 113372 50476 A58
AL9 V AM12-16 37451
1VM50
50520
AK134
50477 A60
AL9 H AM12-16 37451 50520 16133 A56
5
AL10 V AM8-13 87500
2VP36
7/8
7955
2AK104
1
16130 A53
AL10 H AM8-13 87500 7955 50475 A49
AL10 V AM14-18 8973
2VP50
30621
2AK124
50476 A58
AL10 H AM14-18 8973 30621 16131 A54
Model RDF 1-65
Open Motor Horz/Vert
Discharge
Drive Option
(See page 21.)
CODE 200 - Motor Sheave CODE 201- Blower Sheave CODE 202 - Belt CODE 203 -
Bushing HP Option P/N Mfr No. Bore P/N Mfr No. Bore P/N Mfr No.
1-1/2
AL7 V AM2-3 13013
1VM50
5/8
113372
AK144
1
88560 A61 -
AL7 H AM2-3 13013 113372 92402 A59 -
AL7-AK8 V AM4-6 37451
7/8
113372 88560 A61 -
AL7-AK8 H AM4-6 37451 113372 92403 A59 -
AL7 V AM4-6 7962
1VL40
5/8
19111
AK84
50475 A49 -
AL7 H AM4-6 7962 19111 50473 A46 -
AL7-AK8 V AM4-6 106748
7/8
19111 50475 A49 -
AL7-AK8 H AM4-6 106748 19111 50473 A46 -
AL7 V AM7-11 7962
1VL40
5/8
18797
AK64
50472 A45 -
AL7 H AM7-11 7962 18797 50470 A43 -
AL7-AK8 V AM7-11 106748
7/8
18797 50472 A45 -
AL7-AK8 H AM7-11 106748 18797 50470 A43 -
2
2 HP Drive Components for Model RDF 1-65 Series 3 only
AL8 V AM2-3 37451
1VM50
1VL40
7/8
113372
AK144
1
88560 A61 -
AL8 H AM2-3 37451 113372 92403 A59 -
AL8 V AM4-6 106748 19111
AK84
50475 A49 -
AL8 H AM4-6 106748 19111 50473 A46 -
AL8 V AM7-11 106748 18797
AK64
50472 A45 -
AL8 H AM7-11 106748 18797 50470 A43 -
2 HP Drive Components for Model RDF 1-65 prior to Series 3
AL8 V AM2-3 13013
1VM50
5/8
113372
AK144
1
88560 A61 -
AL8 H AM2-3 13013 113372 92403 A59 -
AL8 V AM4-6 7962
1VL40
19111
AK84
50475 A49 -
AL8 H AM4-6 7962 19111 50473 A46 -
AL8 V AM7-11 7962 18797
AK64
50472 A45 -
AL8 H AM7-11 7962 18797 50470 A43 -
3
AL9 V AM4-7 87500
2VP36
7/8
113382
AK144
1
92402 A59 -
AL9 H AM4-7 87500 113382 50476 A58 -
AL9 V AM8-11 6599
2VP42
30622 2AK134H 50476 A58 92203
AL9 H AM8-11 6599 30622 16133 A56 92203
5
AL10 V AM7-13 87500
2VP36 7/8
7955
2AK104 1
65404 A51 -
AL10 H AM7-13 87500 7955 88558 A50 -
NOTE : Where 575V (AK8) is listed, the two corresponding AL option lines above apply to all other voltages with that HP.
Model RDF 2-80 with a CLASS 2 BLOWER
Open Motor Horz/Vert
Discharge
Drive Option
(See page 21.)
CODE 200 - Motor Sheave CODE 201 - Blower Sheave CODE 202 - Belt CODE 203
- Bushing HP Option P/N Mfr No. Bore P/N Mfr No. Bore P/N Qty Mfr No.
2
2 HP Drive Components for Model RDF 2-80 Series 3 only
AL8 V AM3-5 106748
1VL40 7/8
114026 BK110H 1-7/16 112531 1 B55 89659
AL8 H AM3-5 106748 114026 92222 1 B53 89659
2 HP Drive Components for Model RDF 2-80 prior to Series 3
AL8 V AM3-5 7962
1VL40 5/8
114026 BK110H 1-7/16 112531 1 B55 89659
AL8 H AM3-5 7962 114026 92222 1 B53 89659
3
AL9 V AM3-4 87500
2VP36
7/8
114027 2AK184H
1-7/16
16558 2 A69 89659
AL9 H AM3-4 87500 114027 16139 2 A67 89659
AL9 V AM5-9 110125
1VP34
114028 AK134H 92402 1 A59 89659
AL9 H AM5-9 110125 114028 16134 1 A57 89659
AL9 V AM10-13 106748
1VL40
114030 AK124H 92402 1 A59 89659
AL9 H AM10-13 106748 114030 16132 1 A55 89659
5
AL10 V AM3-4 87500
2VP36
7/8
114027 2AK184H
1-7/16
16558 2 A69 89659
AL10 H AM3-4 87500 114027 16139 2 A67 89659
AL10 V AM5-6 87500 114032 2B5V160 92276 2 BX65 114033
AL10 H AM5-6 6599 2VP42 114027 2AK184H 16139 2 A67 89659
AL10 V AM7-11 87500
2VP36
114034 2AK124H 50476 2 A58 89659
AL10 H AM7-11 87500 114034 16132 2 A55 89659
7-1/2
AL11 V AM6-7 113802 2VP68
1-3/8
89651 2BK160H
1-7/16
114104 2 B66 89659
AL11 H AM6-7 114249 2VP71 89651 92414 2 B64 89659
AL11 V AM8-9 106257
2VP60
113811 2BK120H 92226 2 B58 89659
AL11 H AM8-9 106257 113811 92224 2 B56 89659
NOTE : Where 575V (AK8) is listed, the two corresponding AL option lines above apply to all other voltages with that HP.
