PRG LIGHTING SYSTEMS NETWORKING GUIDE

Figure 49: Maxxyz™ System w/ PRG Series 400® Rack and Nodes in S400 Mode

NODE

FRONT OF HOUSE

SERIES 400 RACK

S-400 TRUNK CABLE

UP TO

500 FT.

FOH BREAKOUT MODULE

ALL ETHERNET COPPER CONNECTIONS
MADE WITH PRG/BELDEN CAT5E CABLE.

Cat5e CABLE

TRUNK CABLE
DMX CABLE

NOTE:

Cat5e

BREAKER MODULE

MAXXYZ CONSOLE

7-PORT COPPER SWITCH

UP TO 32 DMX OUTPUTS

NODE

TO OTHER NODES

(ArtNet DATA)

OR SERIES 400

OR ARTNET DEVICE

NODE OR NODE PLUS
