PRG LIGHTING SYSTEMS NETWORKING GUIDE 16
Figure 4: V676® System w/ PRG Series 400® Rack, A/B Switch, 10-Port (Fiber) Ethernet Switch, and Node or Node Plus in S400 Mode
FOH BREAKOUT MODULE
DMX
FOH BREAKOUT MODULE
FOH A/B
SWITCH
A B
S-400 TRUNK CABLE A
500 FT.
UP TO
B
DMX
2ND RACK S400 RACK
NODE OR NODE PLUS
SERIES 400 RACK
DMX OUT
(ArtNet DATA) USING FIBER
10-PORT FIBER SWITCH
BREAKER MODULE
A B
B
A
FRONT OF HOUSE
TO TO
10-PORT FIBER SWITCH
MADE WITH PRG/BELDEN CAT5E CABLE.
ALL ETHERNET COPPER CONNECTIONS
Cat5e CABLE
DMX CABLE
NOTE:
TRUNK CABLE
V676
CONSOLE
V676
CONSOLE
