PRG LIGHTING SYSTEMS NETWORKING GUIDE 32
Figure 20: Virtuoso ® and Conventional Consoles w/ PRG Series 400 Rack®, 7-Port (Copper) Ethernet Switches and Node Plus in Virtuoso Mode
UP TO
A
500 FT.
B
Cat5e CABLE
DMX CABLE
TRUNK CABLE
ALL ETHERNET COPPER CONNECTIONS
MADE WITH PRG/BELDEN CAT5E CABLE.
NOTE:
VIRTUOSO
CONSOLE
FOH BREAKOUT MODULE
Cat5e CONSOLE
VIRTUOSO
Cat5e
DMX
CONVENTIONAL LIGHTING CONSOLE
(Virtuoso DATA)
100 METER MAX.
TO OTHER SWITCHES
7-PORT COPPER SWITCH
B
A
B
BREAKER MODULE
FRONT OF HOUSE
A
(ArtNet DATA)
TO NEXT RACK OR NODE
7-PORT COPPER SWITCH
NODE PLUS
SERIES 400 RACK
NODE PLUS
NODE PLUS
NODE PLUS
NODE PLUS
FOH BREAKOUT MODULE
S-400 TRUNK CABLE
