PRG LIGHTING SYSTEMS NETWORKING GUIDE 56
Figure 44: MagicQ 100 System w/ A/B Switch Configuration Using All PRG Series 400® Components
MAGIC Q100 CONSOLE
MAGIC Q100 CONSOLE
A
TRUNK CABLE
Cat5e CABLE
DMX CABLE
NOTE:
FOH BREAKOUT MODULE
DMX
B A
SWITCH
FOH A/B
FOH BREAKOUT MODULE
S-400 TRUNK CABLE
UP TO
500 FT.
B
A
DMX
S400 RACK
OR OTHER
ARTNET DEVICE
TO
(ArtNet DATA)
TO
2ND RACK
USING FIBER
ALL ETHERNET COPPER CONNECTIONS
MADE WITH PRG/BELDEN CAT5E CABLE.
10-PORT FIBER SWITCH
B
B
FRONT OF HOUSE
A
BREAKER MODULE
SERIES 400 RACK
