PRG LIGHTING SYSTEMS NETWORKING GUIDE

Virtuoso Console Systems

Figure 10: Virtuoso

System w/ PRG Series 400® Rack, 10-Port (Fiber) Ethernet Switches and Node Plus Units in S400 Mode

CONSOLE

VIRTUOSO

CONSOLE

VIRTUOSO

MADE WITH PRG/BELDEN CAT5E CABLE.

ALL ETHERNET COPPER CONNECTIONS

Cat5e CABLE

FIBER CABLE

NOTE:

TRUNK CABLE

A
B

FRONT OF HOUSE

BREAKER MODULE

S-400 TRUNK CABLE

Cat5e

FOH BREAKOUT MODULE

Cat5e

500 FT.

UP TO

10-PORT FIBER SWITCH

NODE PLUS

SERIES 400 RACK

(Virtuoso DATA)

FIBER TO OTHER
FIBER SWITCHES

10-PORT FIBER SWITCH

FIBER SWITCHES

FIBER TO OTHER

(ArtNet DATA)

OR OTHER ARTNET DEVICES

TO SERIES 400 RACK
