PRG LIGHTING SYSTEMS NETWORKING GUIDE
60
Maxxyz Console Systems
Figure 48: Maxxyz™ System w/ A/B Switch Configuration Using a Combination of Node Units in S400 Mode and PRG Series 400® Rack
FOH BREAKOUT MODULE
A
SWITCH
FOH A/B
B
FOH BREAKOUT MODULE
S-400 TRUNK CABLE
UP TO
500 FT.
B
A
DMX
DMX
MAXXYZ CONSOLE
TRUNK CABLE
DMX CABLE
Cat5e CABLE
ALL ETHERNET COPPER CONNECTIONS
MADE WITH PRG/BELDEN CAT5E CABLE.
NOTE:
SERIES 400 RACK
OR SERIES 400
NODE OR NODE PLUS
BREAKER MODULE
A
B
B
A
FRONT OF HOUSE
ADDITIONAL DMX OUTPUTS
OR ARTNET DEVICE
(ArtNet DATA)
TO OTHER NODES
7-PORT COPPER SWITCH
NODE OR NODE PLUS
ArtNet
MAXXYZ CONSOLE
