PRG LIGHTING SYSTEMS NETWORKING GUIDE 57
Figure 45: MagicQ 100 System in a Tracking Backup Configuration Using PRG Series 400® Rack and Node or Node Plus Units in S400 Mode
UP TO
500 FT.
ALL ETHERNET COPPER CONNECTIONS
MADE WITH PRG/BELDEN CAT5E CABLE.
Cat5e CABLE
TRUNK CABLE
DMX CABLE
Cat5e NOTE:
Cat5e
A B
B
A
(ArtNet DATA)
TO SERIES 400 RACK
OR ARTNET DEVICE
DMX OUT
NODE OR NODE PLUS
MAGIC Q100 CONSOLE
MAGIC Q100 CONSOLE
SERIES 400 RACK
BREAKER MODULE
FRONT OF HOUSE
NODE OR NODE PLUS
7-PORT COPPER SWITCH
TO OTHER NODES
S-400 TRUNK CABLE
FOH BREAKOUT MODULE
