PRG LIGHTING SYSTEMS NETWORKING GUIDE 20
Figure 8: V676® and Conventional Consoles w/ PRG Series 400® Rack, 7-Port (Copper) Ethernet Switches, and Node Plus Units in V676 Mode
SERIES 400 RACK
B
A
B
BREAKER MODULE
FRONT OF HOUSE
A
(ArtNet DATA)
TO NEXT RACK OR NODE
7-PORT COPPER SWITCH
NODE PLUS
7-PORT COPPER SWITCH
NODE PLUS
NODE PLUS
NODE PLUS
NODE PLUS
FOH BREAKOUT MODULE
S-400 TRUNK CABLE
UP TO
A
500 FT.
B
Cat5e CABLE
DMX CABLE
TRUNK CABLE
ALL ETHERNET COPPER CONNECTIONS
MADE WITH PRG/BELDEN CAT5E CABLE.
NOTE:
FOH BREAKOUT MODULE
Cat5e
Cat5e
DMX
CONVENTIONAL LIGHTING CONSOLE
(V676 DATA)
100 METER MAX.
TO OTHER SWITCHES
V676
CONSOLE
V676
CONSOLE
