PRG LIGHTING SYSTEMS NETWORKING GUIDE
29
Figure 17: Virtuoso
®
System w/ PRG 7-Port (Copper) Ethernet Switch and Standard Node Units
NODE
NODE
24 POTENTIAL DMX
UNIVERSES OUT
TO ADDITIONAL RACKS
NODE
NODE
100 METER
7-PORT COPPER SWITCH
MAX
ALL ETHERNET COPPER CONNECTIONS
MADE WITH PRG/BELDEN CAT5E CABLE.
TRUNK CABLE
NOTE:
Cat5e CABLE
DMX CABLE
VIRTUOSO
CONSOLE
Cat5e
CONSOLE
VIRTUOSO
Cat5e
