PRG S400 Systems Networking Guide - Manual (Page 47)

PRG LIGHTING SYSTEMS NETWORKING GUIDE 46
Figure 34: Hog ® 3 and Conventional Consoles w/ PRG Series 400® Rack, 10-Port (Fiber) Ethernet Switch and DMX512 Processors
PROCESSORS
FIBER TO OTHER
RACKS OF DMX
SERIES 400 RACK
DMX PROCESSOR
DMX PROCESSOR
10-PORT FIBER SWITCH
Cat5e
A B
A
DMX PROCESSOR
DMX PROCESSOR
DMX PROCESSOR SERIES 400 RACK
FRONT OF HOUSE
BREAKER MODULE
B
DMX
S-400 TRUNK CABLE
FOH BREAKOUT MODULE
Cat5e
UP TO
HOG 3 CONSOLE
500 FT.
CONVENTIONAL LIGHTING CONSOLE
FOH BREAKOUT MODULE
A
Cat5e
B
HOG 3 CONSOLE
Cat5e CABLE
DMX CABLE
TRUNK CABLE
MADE WITH PRG/BELDEN CAT5E CABLE.
ALL ETHERNET COPPER CONNECTIONS
NOTE:
