PRG LIGHTING SYSTEMS NETWORKING GUIDE 13
DIAGRAMS
V676 Console Systems
Figure 1: V676® System w/ PRG Series 400® Rack, 10-Port (Fiber) Ethernet Switches, and Node Plus Units in S400 Mode
10-PORT FIBER SWITCH
NODE PLUS
NODE PLUS
NODE PLUS
NODE PLUS
NODE PLUS
SERIES 400 RACK
(V676 DATA)
FIBER TO OTHER
FIBER SWITCHES
10-PORT FIBER SWITCH
FIBER SWITCHES
FIBER TO OTHER
(ArtNet DATA)
OR OTHER ARTNET DEVICES
TO SERIES 400 RACK
B A
A
B
FRONT OF HOUSE
BREAKER MODULE
S-400 TRUNK CABLE
Cat5e
FOH BREAKOUT MODULE
Cat5e
500 FT.
UP TO
MADE WITH PRG/BELDEN CAT5E CABLE.
ALL ETHERNET COPPER CONNECTIONS
Cat5e CABLE
FIBER CABLE
NOTE:
TRUNK CABLE
V676
CONSOLE
V676
CONSOLE
