PRG LIGHTING SYSTEMS NETWORKING GUIDE 41
Figure 29: GrandMA Consoles w/ PRG Series 400® Rack System, 10-Port (Fiber) Ethernet Switch and NSP Processors
GrandMA CONSOLE
A M
GrandMA CONSOLE
A M
10-PORT FIBER SWITCH
A M
NSP
A M
NSP
TO 2ND RACK
USING FIBER
(MaNet DATA)
NSP
NSP
NSP
Cat5e
S-400 TRUNK CABLE
500 FT.
UP TO
Cat5e
FOH BREAKOUT MODULE
Cat5e
A M
A M
A M
A
SERIES 400 RACK
FRONT OF HOUSE
BREAKER MODULE
A B
B
SERIES 400 RACK
MADE WITH PRG/BELDEN CAT5E CABLE.
Cat5e CABLE
DMX CABLE
TRUNK CABLE
ALL ETHERNET COPPER CONNECTIONS
NOTE:
