PRG LIGHTING SYSTEMS NETWORKING GUIDE 12
Ethernet Cables
The following is a list of standard Ethernet cables for use with PRG lighting
systems. These cables meet the necessary quality specifications and are
the
only Ethernet cables that should be used with PRG systems.
Bold = standard, Non-Bold = non-standard but acceptable.
Fiber Optic Cables
Fiber optic provides the ability to transmit more information, more quickly,
over longer distances with high bandwidth, light-weight cabling. Fiber optic
can reliably send data up 2 kilometers away without the need for repeaters.
Due to the dielectric nature of optical fiber, this cable choice also
eliminates concern for proximity to Electromagnetic and Radio Frequency
Interference.
PRG Fiber Optic Cables are specifically designed for demanding touring
and stage applications with ruggedized LEMO® connectors and military
style cabling. These cables are recommended for use with all PRG
systems.
The Series 400 10-Port Ethernet Switch includes three fiber optic Ethernet
ports for transmission of 100Base-FX standard signal. (Two ports which
accept a PRG Fiber Optic Cable
input connector and one port which
accepts a PRG Fiber Optic Cable output connector.)
The V676, Virtuoso VX and Virtuoso DX2 consoles also offer fiber optic
ports.
CAUTION: No more than 5 fiber optic cables can be connected
in series due to signal loss at the connectors.
TEAM Part No. Cable Type Length (Feet)
39857 RJ45 CAT5e 1
3985C RJ45 CAT5e 5
3985E RJ45 CAT5e 10
3985G RJ45 CAT5e 15
3985J RJ45 CAT5e 25
39752 EtherCon CAT5e 1
39758 EtherCon CAT5e 5
39762 EtherCon CAT5e 10
39765 EtherCon CAT5e 15
39768 EtherCon CAT5e 20
39770 EtherCon CAT5e 25
39773 EtherCon CAT5e 50
39776 EtherCon CAT5e 75
39779 EtherCon CAT5e 100
39782 EtherCon CAT5e 150
39786 EtherCon CAT5e 200
39790 EtherCon CAT5e 300
39792 EtherCon CAT5e 330
TEAM Part No. Cable Type Length (Feet)
37995-60 LEMO Fiber Optic 20
37995-67 LEMO Fiber Optic 125
37995-68 LEMO Fiber Optic 150
38135-10 LEMO Fiber Optic 200
37995-74 LEMO Fiber Optic 350
