PRG LIGHTING SYSTEMS NETWORKING GUIDE 33
Figure 21: Virtuoso ® Consoles w/ PRG Series 400® Rack, 7-Port (Copper) Ethernet Switches and Node Plus Units
SERIES 400 RACK FOH BREAKOUT MODULE
Cat5e
FOH BREAKOUT MODULE
S-400 TRUNK CABLE B
A
B
BREAKER MODULE
FRONT OF HOUSE
A
UP TO
500 FT.
B
A
Cat5e
NODE PLUS
NODE PLUS
NODE PLUS
TO NEXT RACK OR NODE
(ArtNet DATA)
7-PORT COPPER SWITCH
7-PORT COPPER SWITCH
(Virtuoso DATA)
100 METER MAX.
TO OTHER SWITCHES
MADE WITH PRG/BELDEN CAT5E CABLE.
ALL ETHERNET COPPER CONNECTIONS
Cat5e CABLE
DMX CABLE
NOTE:
TRUNK CABLE
NODE PLUS
VIRTUOSO
CONSOLE
VIRTUOSO
CONSOLE
