PRG LIGHTING SYSTEMS NETWORKING GUIDE

Figure 5: V676® System w/ PRG 10-Port (Fiber) Ethernet Switches and Standard Node Units

42 POTENTIAL DMX UNIVERSES OUT

(DMX DATA)

NODE

10-PORT FIBER SWITCH

FIBER TO OTHER
FIBER SWITCHES

(V676 DATA)

NODE

FIBER

FIBER CABLE

MADE WITH PRG/BELDEN CAT5E CABLE.

ALL ETHERNET COPPER CONNECTIONS

NOTE:

DMX CABLE
Cat5e CABLE

CONSOLE AND RACK JUMP MADE WITH
FIBER OPTIC CABLE.

V676

CONSOLE

V676

CONSOLE
