PRG LIGHTING SYSTEMS NETWORKING GUIDE

Figure 2: V676® System w/ PRG Series 400® Rack, 7-Port (Copper) Ethernet Switches, and Node Plus Units in S400 Mode

SERIES 400 RACK

A
B

BREAKER MODULE

FRONT OF HOUSE

NODE PLUS

7-PORT COPPER SWITCH

TO NEXT RACK OR NODE

(ArtNet DATA)

NODE PLUS

7-PORT COPPER SWITCH

TO OTHER SWITCHES

S-400 TRUNK CABLE

DMX CABLE

TRUNK CABLE

Cat5e CABLE

MADE WITH PRG/BELDEN CAT5E CABLE.

ALL ETHERNET COPPER CONNECTIONS

NOTE:

Cat5e

FOH BREAKOUT MODULE

Cat5e

500 FT.

UP TO

(V676 DATA)

100 METER MAX.

V676

CONSOLE

V676

CONSOLE
