PRG S400 Systems Networking Guide User Manual

Page 31

PRG LIGHTING SYSTEMS NETWORKING GUIDE

Figure 18: Inserting and Sending Virtuoso

or V676® Data

7-PORT COPPER SWITCH

TO ADDITIONAL RACKS

VIRTUOSO or V676 PROTOCOL

NODE

30 POTENTIAL DMX
UNIVERSES OUT

NODE

ALL ETHERNET COPPER CONNECTIONS

INSERT DATA FROM ANOTHER RACK OR

THIS SYSTEM SETUP CAN BE USED TO

FIBER CABLE
DMX CABLE
Cat5e CABLE

MADE WITH PRG/BELDEN CAT5E CABLE.

NOTES:

CONSOLE, AND FOR SENDING DATA TO
ADDITIONAL RACKS.
