PRG LIGHTING SYSTEMS NETWORKING GUIDE 15
Figure 3: V676® System w/ PRG 10-Port (Fiber) Ethernet Switches, Node Plus Unit in V676 Mode, and Series 400® Rack
10-PORT FIBER SWITCH
10-PORT FIBER SWITCH
FIBER
SERIES 400 RACK
(ArtNet DATA)
TO SERIES 400 RACK
OR OTHER ARTNET DEVICES
NODE PLUS
NODE PLUS
NODE PLUS
FIBER TO OTHER
FIBER SWITCHES
BREAKER MODULE
FRONT OF HOUSE NODE PLUS
NODE PLUS
FIBER SWITCHES
FIBER TO OTHER
(V676 DATA)
B
A B
A
FIBER
FIBER OPTIC CABLE.
CONSOLE AND RACK JUMP MADE WITH
ALL ETHERNET COPPER CONNECTIONS
MADE WITH PRG/BELDEN CAT5E CABLE.
NOTE:
Cat5e CABLE
DMX CABLE
FIBER CABLE
V676
CONSOLE
V676
CONSOLE
