NeoTherm LC Boilers and Water Heaters

Page 83

Label

Description

How to Reach

CH (Central

Heat)

Setpoint

This setpoint is used when the time-of-day input

is off. If the outdoor reset function is active, this

setpoint provides one coordinate for the outdoor

reset curve. See the section for the CH Outdoor

Reset parameter.

If Lead/Lag enabled –

<’home’ screen> Lead/Lag Master button

Configure

button

screen>

CH (Central

Heat) “Time

of Day”

Setpoint

This setpoint is used when the time-of-day input

is on. If the outdoor reset function is active,

this Setpoint provides one coordinate for the

shifted outdoor reset curve, because the time-

of-day switch is on. See the section for the CH

Outdoor Reset parameter.”

If Lead/Lag enabled –

<’home’ screen> Lead/Lag Master button

Configure

button

screen>

DHW

(Domestic

Hot Water) D

Gain

This gain applied to the Differential term of the

PID equation for the DHW loop.

<’home’ screen> Select a controller

Configure

button

Configuration screen>

DHW

(Domestic

Hot Water)

Enable

This parameter determines whether the

Domestic Hot Water loop is enabled or disabled.

When it is disabled, the demand caused by the

DHW sensor is ignored. It may be disabled to

turn it off temporarily or because the application

does not use this feature.

<’home’ screen> Select a controller

Configure

button

Configuration screen>

DHW

(Domestic

Hot Water)

has priority

over CH

(Central

Heat)

This parameter determines the priority of

Domestic Hot Water vs. Central Heat call-for-

heat, when both of these are enabled and active.

(The DHW priority also may shift for a period

of time, as specified by DHW Priority time and

method parameters.)”

<’home’ screen> Lead Lag Master

Lag Master screen> Configure button

Advanced Settings button/ Left- and

Right- arrow buttons

Water screen>

DHW

(Domestic

Hot Water) I

gain

This gain applied to the Integral term of the PID

equation for the DHW loop.

<’home’ screen> Select a controller

Configure

button

Configuration>

DHW

(Domestic

Hot Water)

off hysteresis

The off hysteresis is added to the Domestic Hot

Water Setpoint to determine the temperature at

which the DHW burner demand turns off.

<’home’ screen> Select a controller

Configure

button

Configuration screen>

DHW

(Domestic

Hot Water)

on hysteresis

The on hysteresis is subtracted from the

Domestic Hot Water Setpoint to determine the

temperature at which the DHW burner demand

turns on.

<’home’ screen> Select a controller

Configure

button

Configuration>

DHW

(Domestic

Hot Water) P

gain

This gain applied to the Proportional term of the

PID equation for the DHW loop.

<’home’ screen> Select a controller

Configure

button

Configuration screen>

DHW

(Domestic

Hot Water)

priority

override time

If this parameter is non-zero then a Domestic

Hot Water demand will shift its priority vs.

other demand sources according to the specified

time. The priority override timing is reset when

demand from the DHW source turns off.

<’home’ screen> Lead Lag Master button

Configure

button

screen> Advanced Settings button
