3BChapter 4: Operating instructions
TruVision DVR 41 User Manual 25
Menu overview
The TVR 41 has an icon-driven menu structure that allows you to configure the
unit’s parameters. Each command icon displays a dialog screen that lets you edit
a group of settings. Most menus are available only to system administrators.
The configuration screen is divided into three sections. The currently selected
command icon and submenu item are highlighted in green. See Figure 10 below.
You must be in live view to access the main menu.
Figure 10: Menu structure
1. Menu toolbar: Setup options available for the selected configuration menu function. Move
the mouse over a command icon and click to select it. See Table 4 below for a description of
the icons.
2. Submenu panel: Submenus for the selected menu function are displayed. Click an item to
select it.
3. Setup menu: All the details for the selected submenu are displayed. Click a field to make
changes.
Table 4: Description of the menu toolbar icons
Icon Name Description
Display mode settings Configures display settings including dwell time, schedule,
language and display formats. See “Configuring live view”
on page 35 and “Holiday schedules” on page 92.
Camera management Configures camera settings including OSD display , motion
detection, video image adjustments, and copy settings to
other cameras. See Chapter 14 “Camera settings” on page
129.
Video schedule Configures recording settings including recording
schedules, record quality, auto delete mode, and recording
mode. See Chapter 10 “Recording” on page 87.
