16BChapter 17: KTD-405 keypad
TruVision DVR 41 User Manual 145
Button Description
Bookmark: Tap to create bookmarks. Bookmarks are groups of cameras that can
be accessed together.
Snapshot: Tap to take a snapshot of the live view images.
PTZ control: Tap to call up the PTZ control arrows on-screen for PTZ control.
To access live view:
1. In the main menu, tap Live to access live view. Live view is in 2X2 multiview
mode by default. The selected video tile has a green frame.
2. Double-tap or to open the list of devices, bookmarks and favorites
available and select the desired camera.
3. Tap the desired device, such as a DVR. All cameras listed under this device
are shown.
4. Tap the desired camera in the list. The live view immediately appears on-
screen. By default it occupies one of the four video tiles.
5. To display another camera in live view, double-tap or again and
select the desired camera from the list. Repeat for the other two video tiles, if
required.
6. To stop live view for a selected camera, select a camera. The selected
camera has a green frame. Tap . A green cross appears in the video tile.
7. To return to the main menu, tap iTVRmobile .
Live view from the camera is not disconnected. You can, for example, change
configuration settings and then return to live view by tapping
again. The
application returns to the live view of the selected camera.
Controlling a PTZ camera
The application supports main and substream in live view. Substream is default.
When selecting the main stream option in live view, please refer to the table
below for the recommended parameter settings:
Table 19: Main stream recommended parameters
Resolution Frame rate Bit rate
XVGA 1 fps 320 Kbps
HD900 1 fps 320 Kbps
720P 1 fps 320 Kbps
