IC Realtime Specialty: 4-CH H.264E CUBE REAL-TIME DVR with BUILT-IN 5.6 LCD User Manual
Page 90
90
Name
Function
key
Function Function
key
Function
Zoom
Near
Far
Focus
Near
Far
Iris
close
Open
Then click triangle icon in Figure 7-10, you can see the following interface. See
Figure 7-11.
Figure 7-11
In Figure 7-11, click PTZ setup button you can see the following interface. See
Figure 7-12.
