2 connection sample, Connection sample – IC Realtime Specialty: 4-CH H.264E CUBE REAL-TIME DVR with BUILT-IN 5.6 LCD User Manual

Page 17

background image

17

7

The first video input
channel

8

Audio output

9

Video output

10

VGA port

11

RS232 port

12

USB port

13

Networkport(RJ45)

14

ALARM-RS485
port

15

Power button

16

Power socket


2.2.2 Connection

Sample

Here is a connection sample for your reference. See Figure 2-5.
