9 preset/ patrol/pattern/scan, Preset/ patrol/pattern/scan, Figure 4-34 – IC Realtime Specialty: 4-CH H.264E CUBE REAL-TIME DVR with BUILT-IN 5.6 LCD User Manual
Page 52: Figure 4-32
52
Figure 4-32
Here is a sheet for you reference.
Name Function
key
function Shortcut
key
Function
key
function Shortcut
Key
Zoom
Near
►
Far
Focus
Near
_
Far
►
Iris
close
W
Open
f
4.9 Preset/ Patrol/Pattern/Scan
In Figure 4-30, click the “set” button. The interface is shown as below. See Figure
4-33.
Here you can set the following items:
z
Preset
z
Patrol(Tour)
z
Pattern
z
Border
Figure 4-33
In Figure 4-30, click page switch button, the interface is shown as in Figure 4-34.
Here you can activate the following functions:
z
Preset
z
Tour
z
Pattern
z
Auto
scan
z
Auto
pan
z
Flip
z
Reset
z
Page
switch
Figure 4-34
