37

4.3 Search & Playback

4.3.1 Search

Menu

There are two ways for you to go to search menu.
z

Click

Pause/Play

button

in the remote control.

z

Click search in the main menu.

Search interface is shown as below. See


Figure 4-10
.
Usually there are three file types:
z

R: regular recording file.

z

A: external alarm recording file.

z

M: motion detection recording file

z

C: card and POS test overlay recording file(For some special series only)

There are several playback windows. System supports 1/2-ch playback.

Figure 4-10

Please refer to the following sheet for more information.

Serial Number

Function

1 Play
2 Backward
3 Stop
4 Slow

play

5 Fast

play

1-window Playback

2-window Playback

File List

Playback Window

File Informa

tion

1 2 4 5 6 7 8 9 10 11

12

14

13

3
