6 Cylinder Engine
INJ1 = 1 st , 3 rd and 5 th cylinder in firing order
INJ2 = 1 st , 3 rd and 5 th cylinder in firing order
INJ3 = 2 nd , 4 th and 6 th cylinder in firing order
INJ4 = 2 nd , 4 th and 6 th cylinder in firing order
8 Cylinder Engine
INJ1 = 1 st and 5 th cylinder in firing order
INJ2 = 2 nd and 6 th cylinder in firing order
INJ3 = 3
rd
and 7
th
cylinder in firing order
INJ4 = 4 th and 8 th cylinder in firing order
B1.3 Staged Injection
Staged injection mode allows the use of two individual injector banks, one for light to
medium loads (Primary), then as fuel requirements increase a second bank are switched on
(Secondary) Staged injection and is usually only used on high boost or turbo charged
engines. Below is how they should be wired for typical applications. Please refer to section
Appendix D3, Staged Injection p100
4 Cylinder Engine
INJ1 = Cylinder 1 & Cylinder 2 Primary Injectors
INJ2 = Cylinder 3 & Cylinder 4 Primary Injectors
INJ3 = Cylinder 1 & Cylinder 2 Secondary Injectors
INJ4 = Cylinder 3 & Cylinder 4 Secondary Injectors
6 Cylinder Engine
INJ1 = Cylinder 1, Cylinder 3 & Cylinder 5 Primary Injectors
INJ2 = Cylinder 2, Cylinder 4 & Cylinder 6 Primary Injectors
INJ3 = Cylinder 1, Cylinder 3 & Cylinder 5 Secondary Injectors
INJ4 = Cylinder 2, Cylinder 4 & Cylinder 6 Secondary Injectors
8 Cylinder Engine
Please contact Haltech with regards to this setup.
