Baro Input
Select either the internal barometric sensor or to use another external barometric
sensor.
INJ x Current
The ECU has four injector outputs: INJ1-INJ4. These have the ability to drive up to
8A peak and 2A hold current through the injector load. The current control options
must be set properly for the number and type of injectors connected to the specific
output (INJ1-INJ4). The appropriate injector current control settings are further
described in the appendix
WARNING:
THE CURRENT CONTROL MUST BE SET CORRECTLTY.
EXCESSIVE CURRENT PASSED THROUGH AN INJECTOR LOAD
FOR A LONG PERIOD OF TIME MAY DAMAGE THE INJECTORS
