Haltech F10X User Manual
Page 109
F10X Manual
109
WARNING:
RARE EARTH MAGNETS ARE EASILY DAMAGED AND THE
PEENING PROCESS (OR LOCATION BY GRUB SCREWS ETC)
SHOULD BE VERY CAREFULLY CARRIED OUT SO AS NOT TO
DAMAGE THE MAGNETS. IF DAMAGED THEY WILL NOT HAVE
SUFFICIENT MAGNETIC STRENGTH OR MAY FAIL
MAGNETICALLY OR PHYSICALLY AFTER A PERIOD OF TIME.
If installed correctly the magnets will have a long life.
Note: In the previous examples, for ease of reference, the magnets are shown
mounted on the circumference of a wheel with the Haltech Hall effect sensor
oriented to one side. If so mounted the magnets need to be mounted with
sufficient strength to resist centrifugal force. In practice the magnets are often
mounted within the circumference of the wheel and the sensor is mounted so
that its base is pointed towards the magnets in the face of the wheel.
