Throttle Position Sensor
10
k
Ω
rotary potentiometer driven from throttle shaft
•
Internal Barometric Pressure Sensor
Barometric pressure compensation only
•
Engine Speed Pickup
Compatible with most trigger systems:
-
5 or 12 volt square wave;
-
Pull-to-ground (open collector)
ECU Outputs
•
Injector Driver
4 x Two State Programmable Peak-and-hold current limiting drivers capable of driving at:
- 4Apk/1Ahold
- 8Apk/2Ahold
The above current specifications allow the drivers to drive up to 8 x 2.2~2.4
Ω
injectors, 16 x saturation
style injectors (High Impedance) or 4 x ~0.5
Ω
.
CAUTION: Ensure software settings are correct since excessive current for long periods may damage
injectors.
•
Pulse Width Modulated (PWM) Output
4 x Dedicated PWM outputs capable of driving: 1A continuous pull to ground
-
Suitable for controlling turbo waste-gate, solenoids, valves, shift lights, relays etc.
•
Fuel Pump Control
20A fused relay, features automatic priming and switch-off.
System Programming Requirements
•
Computer
IBM-PC or compatible, preferably laptop or notebooks
CGA, EGA or VGA, colour or monochrome display
640+ kb RAM
•
Disk Drive
3.5" Floppy Disk Drive
•
Serial Port
Standard RS232C port - 9 pin D connector
COM1 or COM2 (selectable)
