F10X Manual
120
APPENDIX H WIRING DIAGRAMS
Pin # Function Wire Colour
1 SPARE A/D RED/BLK
2 O2 SENSOR GRY
3 PWM OUT 2 PINK/BLK
4 PWM OUT 1 VIO/WHT
5 ROAD SPEED GRY/YEL
6 TRIGGER YEL
7 +13VDC ECU RED/WHT
8 TX RED
9 RX BLU
10 TRIM BLK/WHT
11 MAP YEL
12 N/C -
13 N/C -
14 IDL4 BRN/WHT
15 IDL3 YEL/RED
16 IDL2 GRN/YEL
17 IDL1 BRN
18 +5VDC ORG
19 INJ1 L. BLU
20 INJ2 BLU/RED
21 INJ3 GRN/RED
22 INJ4 PINK
23 PWM OUT 3 BLU/GRN
24 PWM OUT 4 GRN/WHT
25 +13VDC ECU RED/WHT
26 GND BLK
27 AUX OUT GRN/BLK
28 AUX IN GRN
29 AIR TEMP GRY
30 COOLANT VIOLET
31 TPS WHITE
32 GND BLK
33 PUMP RELAY BLK/YEL
34 N/C -
35 N/C -
36 COIL NEG/TACHO OUT TRIGGER L. GRN
