F10X Manual
94
B1.1 Multipoint Injection
Multipoint mode injection fires all of the injectors simultaneously. Below is how they should
be wired for typical applications.
4 Cylinder Engine
INJ1 = Cylinder 1 Injector
INJ2 = Cylinder 2 Injector
INJ3 = Cylinder 3 Injector
INJ4 = Cylinder 4 Injector
6 Cylinder Engine
INJ1 = Cylinder 1 & Cylinder 2 Injectors
INJ2 = Cylinder 3 & Cylinder 4 Injectors
INJ3 = Cylinder 5 & Cylinder 6 Injectors
8 Cylinder Engine
INJ1 = Cylinder 1 & Cylinder 2 Injectors
INJ2 = Cylinder 3 & Cylinder 4 Injectors
INJ3 = Cylinder 5 & Cylinder 6 Injectors
INJ4 = Cylinder 7 & Cylinder 8 Injectors
B1.2 Batch Injection
Batch mode injection fires the injectors in two even groups. This is aimed at reducing fuel
pressure rail fluctuations. The F10 will fire INJ1 & INJ2 as one group and INJ3 & INJ4 as the
second group. Below is how they should be wired for typical applications.
4 Cylinder Engine
INJ1 = 1 st cylinder in firing order
INJ2 = 2 nd cylinder in firing order
INJ3 = 3 rd cylinder in firing order
INJ4 = 4 th cylinder in firing order
