7

A QUICK INTRODUCTION TO THE 10C SYSTEM

TRANSMITTER:

• Large graphic liquid-crystal display panel with 2 buttons, a cursor lever and an easy set up turn-and-press Dial for quick,
easy setup.

• All transmitters include all 3 aircraft types with specialized programming for each, including:

• Airplane (ACRO)

• V-TAIL

• Twin Aileron Servos (FLAPERON and AIL-DIFF)

• Gyro Mixing

• ELEVON

• Twin Elevator Servos (AILEVATOR)

• AIRBRAKE

• Snap Roll (4 separate directions available)

• Helicopter (8 swashplate types, including CCPM, see page 93)(HELI)

• 3 Idle Ups

• Throttle and Pitch Curves per Condition

• Revo. Mixing

• Gyro Mixing including Separate Settings per Condition

• Delay

• Governor Mixing

‡6DLOSODQH*OLGHUZLQJW\SHVGLID 1AIL+1FLP2AIL+1FLP2AIL+2FLP)

• V-TAIL

• Twin Ailerons (FLAPERON and AIL-DIFF

‡)OLJKW&RQGLWLRQV1RUPDO6WDUW

• ELEVON

• Crow (BUTTERFLY

6SHHG'LVWDQFH/DQGLQJ

• OFFSET (5 conditions)

• BASIC menu for quick, easy set up of less complex models.

• ADVANCE menu for more complex, unique setups.

• Four electronic TRIM LEVERS for rapid yet precise trim adjustment - no remembering to “store trims” between models

and no more “bumped trims” during transport.

• IDLE- DOWN (ACRO), THR-CUT (ACRO

HELI) (engine shut off), and MOTOR CUT (GLIDVHWXSVWRDOORZSUHFLVHHQJLQHPRWRU

control for taxi and landings.

‡FRPSOHWHPRGHOPHPRULHVZLWKPRUHSHURSWLRQDOCAMPac...
• New stick design with improved feel, adjustable length and tension.

• Triple rates available by setting dual rates to 3-position switches.

• Eight SWITCHES, 3 DIALS and 2 SLIDERS; completely assignable in most applications.

• Trainer system includes the “functional” (FUNC) setting, which allows the student to use the 10C’s mixing, helicopter, and

other programming functions even with a 4-channel buddy box. (Optional trainer cord required.)

• With a TP-FM module: transmits in both FM (PPM) and PCM

E\ VHOHFWLQJ PRGXODWLRQF\FOLQJ WUDQVPLWWHU 5HTXLUHV

receiver of proper modulation.

With a TM-10 2.4GHz module: transmits in both 2.4G-7CH and 2.4G-10CH

E\VHOHFWLQJPRGXODWLRQF\FOLQJWUDQVPLWWHU

Requires receiver of proper modulation.

• Permanent memory storage via EEPROM with no backup battery to service or have fail.

• 10CA transmitter features airplane friendly switch layout, with the trainer switch at the left hand (Mode 2), and a notched

throttle to minimize throttle changes with rudder input. Defaults to ACRO model type.

• 10CH transmitter features helicopter-friendly switch layout, with idle-up and throttle hold switches at the left hand, and a

smooth, ratchet-less (unsprung) throttle for perfect hovering. Defaults to HELI(H-1 swashplate type) model type.

• Change transmitter mode from mode 2 to modes 1, 3, or 4. (See P. 17)

Note that in the text of this manual, beginning at this point, any time we are using a feature’s specialized name or
abbreviation as seen on the screen of the 10C, that name, feature, or abbreviation will be exactly as seen on the radio’s
screen, including capitalization and shown in a DIFFERENT TYPE STYLE

IRUFODULW\$Q\WLPHZHPHQWLRQDVSHFL¿FFRQWURO

on the radio itself, such as moving SWITCH A, KNOB VR(B), or the THROTTLE STICK, those words will be displayed
as they are here.
