TIMER
submenu (stopwatch functions): controls three electronic clocks used to keep track of time remaining in a
FRPSHWLWLRQWLPHDOORZHGÀ\LQJWLPHRQDWDQNRIIXHODPRXQWRIWLPHRQDEDWWHU\HWF
Adjustability:
• Count down timer: starts from the chosen time, displays time remaining. If the time is exceeded, it continues to count
below 0.
• Count up timer: starts at 0 and displays the elapsed time up to 99 minutes 59 seconds.
• Count down timer (Stop type): starts from the chosen time, displays time remaining, and stops at 0.
• Model timer: cumulates ON time up to 99 hours 59 minites each model. Once Model timer function is turned off, the
cumulate time will also be reset to "0:00".
• Independent to each model, and automatically updates with model change.
• In either TIMER mode, the timer beeps once each minute. During the last twenty seconds, there's a beep each two seconds.
'XULQJWKHODVWWHQVHFRQGVWKHUHVDEHHSHDFKVHFRQG$ORQJWRQHLVHPLWWHGZKHQWKHWLPHVHOHFWHGLVUHDFKHG83
DOWN TIMER)
• To Reset, choose the desired timer with the CURSOR lever (while at the startup screen), then press and hold DIAL for 1
second.
• Activation by either direction of SWITCH A-H, by THROTTLE STICK (STK-THR) (Using the THROTTLE STICK is
convenient if you are keeping track of fuel remaining, or for an electric, how much battery is left), by LOGIC SWITCH
Lsw1-Lsw3 or by the power SWITCH (PWR SW). Set up LOGIC SW: See p. 38.
• Also the reset switch can be assigned (SWITCH A-H or LOGIC SWITCH Lsw1-Lsw3)
GOAL of EXAMPLE:
STEPS:
INPUTS:
6HWWLPHUWRFRXQWGRZQPLQXWHV
b e i n g c o n t r o l l e d b y T H R O T T L E
STICK position. This is utilized to keep
track of actual Throttle on time to better
FRUUHODWHZLWKIXHOEDWWHU\XVDJH
Open BASIC menu, then open TIMER
function.
for 1 second.
(If ADVANCE,
again.)
to page 2.
C
to TIMER.
Go to TIMER<2>.
C
to 10 (TIMER<2>).
Adjust time to 4 min. 30 sec., count
down.
to 4.
C
to 00 (TIMER<2>).
to 30.
Assign to THROTTLE STICK and set
trigger point.
C
to ON>SwA (TIMER<2>).
to STK THR.
C
to 50%.
for 1 second to NULL.
THROTTLE STICK to desired
SRVLWLRQ([VWLFN
for 1 second to set.
Close.
Where next?
Adjust END POINTs
DIWHU¿UVWÀLJKWWHVWVHHS
$GMXVWDX[LOLDU\FKDQQHODVVLJQPHQWVH[PRYHÀDSVWRDVZLWFKVHHS
Set up TRAINER functions: see p. 47.
TIMER<1>
TIMER<2>
TIMER<3>
(Home screen)
