Page 55
55
Using Twin Aileron Servos with a 5-channel receiver, AILE-2 (ACRO
GLID ):
AILE-2
allows FLAPERON and AIL-DIFF with a 5-channel receiver. AILE-2 only tells
the radio that you are using CH5 and CH6 (FLAPERON), or CH5 and CH7 (AIL-
DIFF
), not CH6 or CH7, as the second servo in FLAPERON or AILE-DIFF. You still
must activate and set up the FLAPERON
AILE-DIFF function.
Note that selecting CH6&5 or CH7&5 does NOT free up CH6 or CH7 to be used for other functions when using a receiver
with more than 5 channels. Both 5 and 6 (FLAPERON
AILE-DIFF) are dedicated to the FLAPERON or AILE-DIFF programming.
>7KLVLVEHQH¿FLDOZLWKIRXUDLOHURQVHUYRVWKDWQHHGWRKDYHWKHLUHQGSRLQWVRUVXEWULPVVHWVHSDUDWHO\&+&+DQG
CH6 are already fully set up to operate as ailerons. Mix CH7 or CH8 (the second aileron servo on the other side) into
ailerons to function properly.]
Aircraft tail types (ACRO
GLID):
GOAL of EXAMPLE:
STEPS:
INPUTS:
Adjust the second aileron servo output
from CH6or7 to channels CH6&5.
Allows twin aileron servo operation
with a 5-channel receiver.
Open the PARAMETER submenu.
for 1 second.
(If ADVANCE,
again.)
C
to PARAMETER.
Select AILE-2 and change to CH6&5.
C
to AILE-2.
to CH6&5.
Close menu.
Where next?
Finish setting up FLAPERON or AILE-DIFF. see Twin Aileron Servos: p. 51.
View additional model setups on the internet: www.futaba-rc.com\faq\
