A QUICK GUIDE: GETTING STARTED WITH A BASIC 4-CHANNEL AIRCRAFT
This guide is intended to help you get acquainted with the radio, to give you a jump start on using your new radio, and
to give you some ideas and direction in how to do even more than you may have already considered. It follows our basic
format of all programming pages: a big picture overview of what we accomplish; a “by name” description of what we're
doing to help acquaint you with the radio; then a step-by-step instruction to leave out the mystery when setting up your
model.
For additional details on each function, see that function's section in this manual. The page numbers are indicated in the
goals column as a convenience to you.
See p.26 for a legend of symbols used.
GOALS of EXAMPLE
STEPS
INPUTS for EXAMPLE
Prepare your aircraft.
Install all servos, switches, receivers per your model's instructions. Turn on
transmitter then receiver; adjust all linkages so surfaces are nearly centered.
Mechanically adjust all linkages as close as possible to proper control throws.
Check servo direction. Make notes now of what you will need to change during
programming.
Name the model.
P. 32.
[ N o t e t h a t y o u d o n o t n e e d t o d o
anything to "save” or store this data.
Only critical changes such as a MODEL
RESET
require additional keystrokes to
accept the change.]
Open the BASIC menu, then open the
MODEL
submenu.
Turn on the transmitter.
for 1 second.
(If ADVANCE,
again.)
C
as needed to highlight MODEL.
to choose MODEL.
Go to MODEL NAME.
C
to NAME.
(First character of model's name is
highlighted.)
Input aircraft's name.
Close the MODEL submenu.
WRFKDQJH¿UVWFKDUDFWHU
When proper character is displayed,
C
to move to next character.
Repeat as needed.
to return to BASIC menu.
Reverse servos as needed for proper
control operation.
P. 38.
I n t h e BASIC m e n u , o p e n ( s e r v o )
REVERSE
.
C
to REVERSE.
to choose REVERSE.
Choose desired servo and reverse its
direction of travel. (Ex: reversing rudder
servo.)
C
to CH4: RUDD.
so REV is highlighted.
Repeat as needed.
Adjust Travels as needed to match
model's recommended throws (usually
listed as high rates).
P. 39.
From BASIC menu, choose END POINT.
C
to END POINT.
to choose END POINT.
Adjust the servo's end points.
(Ex: throttle servo)
Close the function.
C
to THROTTLE.
THROTTLE STICK.
until carb barrel closes as desired.
THROTTLE STICK.
until throttle arm just opens carb
fully at full THROTTLE STICK.
Repeat for each channel as needed.
